Data Sheet

Data sheet | Item number:769-106
www.wago.com/769-106
06.12.2018Page /2 8
Ratings per IEC/EN 60664-1
Rated voltage (III / 3) 500 V
Rated impulse voltage (III / 3) 6 kV
Rated current 32 A
Legend (ratings) (III / 3) ≙ Overvoltage category III / Pollution degree 3
Connection data
Connection technology
CAGE CLAMP
®
Actuation type Operating tool
Connectable conductor materials Copper
Aluminum
Nominal cross section 4 mm²
Solid conductor 0.08 … 4 mm² / 28 … 12 AWG
Fine-stranded conductor 0.08 … 4 mm² / 28 … 12 AWG
Strip length 8 … 9 mm / 0.31 … 0.35 Inch
No. of poles 6
Total number of connection points 6
Total number of potentials 6
Type of wiring Front-entry wiring
Geometrical Data
Width 30 mm / 1.181 inch
Height 45.2 mm / 1.78 inch
Depth 18.3 mm / 0.72 inch
Mechanical data
Marking level Side marking
Plug connection
Contact type (pluggable connector) Female connector/socket
Connector connection type for conductors
Material Data
Color gray
Insulating material Polyamide 66 (PA 66)
Fire load 0.32 MJ
Weight 18.856 g
