Quick Start Guide

8 9
4
MOUNT THE AP
Power
Off: Powered off
Green: Operation at full power (PoE+ DC)
Flashing: Cannot connect to Wi-Fi Cloud or controller
Amber: Operation at reduced power (PoE)
Flashing: No IP address received from DHCP
2.4 GHz, 5 GHz, Third Radio
Off: Wireless radio inactive
Green: Wireless radio active
Uplink (WAN)
Off: No Ethernet link
Green: Connected to network
5
CHECK AP STATUS
Align
grooves and
slide AP on
to bracket
LAN Interfaces
Off: No Ethernet link
Green: Connected to network
