Specifications

Antique Brass - AB
Antique Bronze - ABZ
Antique Copper - AC
American Bronze - AMB
Antique Pewter - AP
Gloss Black - GB
Black Nickel - BLN
Black-Oil Rubbed Bronze - ORB
Caribbean Bronze - CB
Chocolate Bronze - CHB
Chrome - CH
Classic Bronze - CLZ
Distressed Antique Brass - DAB
Distressed Antique Copper - DAC
Distressed American Bronze - DAMB
Distressed Antique Pewter - DAP
Matte Black - MB
Polished Brass - PB
Polished Copper - PC
Polished Gold - PG
Polished Nickel - PN
Satin Brass - SB
Satin Chrome - SC
Satin Gold - SG
Satin Nickel - SN
Stainless Steel - SS*
Tuscan Brass - TB
Unlaquered Polished Brass - UPB
Venetian Bronze - VB
Weathered Brass - WB
Weathered Copper - WC
41180 Raintree Court • Murrieta, CA 92562 • 1-888-304-0660 • Fax [phone] • www.waterstoneco.com
REVISED: 4-16-18
*Contemporary Styles Only
AVAILABLE IN 30 FINISHES + SOLID 316 MARINE GRADE STAINLESS STEEL
• Max Counter Thickness 2-3/8”
• Minimum Install Hole Size 1-3/8"
Supply Hoses - 20” Long with
3/8” Compression Fittings
2-1/8”
1-1/4”
2-1/4”
12-3/4”
13-1/4”
9”
2-3/8”
3-1/8”
6-3/8”
26-5/8”
23-3/4”
32-3/4”
6-1/4”
2”
10-5/8”
10-3/4”
3-1/4”
1-7/8”
5-1/4”
DIMENSIONS MAY VARY AND ARE SUBJECT TO CHANGE. NO RESPONSIBILITY IS ASSUMED FOR USE OF SUPERCEDED OR VOIDED DATA
Model # 4400
GANTRY
®
PULLDOWN FAUCET - HOOK SPOUT
PRODUCT DESCRIPTION
• Unique patent protected design.
• Hook spout with 10-3/4” reach.
• Spout swivels 360 degrees.
• Built-in diverter for pre-rinse sprayer.
• Spray arm pivots to reach all areas of sink.
• Select lever spray or aerated stream.
• Adjustable PTFE “Friction Lock” helps handle feel and
prevents sag.
• Handle adjusts 22.5 degrees in either direction for
backsplash clearance.
• Single handle mounts in front, right or left hand positions.
• Hot/Cold ceramic disk valve cartridge.
• Compatible with reverse osmosis ltration systems.
• 1.75 gpm maximum ow rate with aerated tip.
• Solid brass construction.
• Includes 3 handle button options.
• Reinforced braided connection hoses.
• Lifetime Functional Warranty.
• Made in the USA.
CODES/STANDARDS APPLICABLE
Specified model meets or exceeds the following:
• ASME A112.18.1
• CSA B125.1
• NSF 61, 372
• CALGreen
Finish shown - Antique Pewter.
