 TD – Indicates when data is transmitted over the T-bus or over the control bridge. is
LED does not indicate data transmitted on the A or B ports.
 RD – Indicates when data is received over the T-bus or over the control bridge. is
LED does not indicate data received on the A or B ports.
Note
If the DC Surge OK LED is not on when the Click 222 is powered, call Wavetronix
Technical Services for assistance.
e Click 222 provides the following three independent serial connections:
 Topmost jack: control bridge
 Middle jack: dedicated communications for sensor 2 detection calls
 Lowest jack: dedicated communications for sensor 1 detection calls
e control bridge enables a multi-drop shared communication bus between all sensors
connected to the backplate. is allows control of all SmartSensor Matrix sensors, rack
cards and other connected Click devices. e remaining two serial connection ports provide
communications to only one sensor each, as outlined above.
On a four-sensor preassembled backplate (see Figure 2.7):
 e sensor wired into the left-most terminal blocks will be connected to ports A and
C on the Click 222 on the left. Port A is for detection calls and port C is connected
to the control bridge.
 e sensor wired to the second set of terminal blocks will be wired to ports B and D
on the Click 222 on the left. Port B is for detection calls and port D is connected to
the control bridge.
 e sensor wired to the third set of terminal block from the left will be wired to ports
A and C on the Click 222 on the right.
 e sensor wired to the right-most terminal block will be wired to ports B and D on
the Click 222 on the right.
