Wearable Bluetooth® Speaker NAS-3100 Instruction Manual Please read carefully before use and keep for future reference.
Thank You In the Box We know you have many choices when it comes to technology; thank you for choosing us here at Naxa Electronics. Established in 2001 in Los Angeles, California, we are dedicated to delivering products that entertain and delight. Please take a moment to make sure that you have everything in the list below. Although we make every effort to ensure that each Naxa device is securely packed and sealed, we know a lot can happen in between us and you.
At a Glance 2 4 1 3 6 7 5 Part Play/Pause/ Phone Button Press to play/pause music playback. Answer/end calls (when connected to a smartphone). 6 Next Track/ Volume Up Press to go to the next track. Hold to increase the volume. 7 Previous Track/ Press to go to the previous track. Volume Down Hold to decrease the volume. 8 Power/ Mode Button Hold to turn the speaker on or off. Press to switch between modes (USB/Card/BT/Aux In/FM). 8 Description 3.
Connecting Power The speaker has a built-in rechargeable battery. When the battery runs out, the speaker turns off automatically. Please recharge the battery. To charge the battery, do as follows : 1. Plug the Micro USB end of the included USB charge cable into the charging port. 2. Plug the other end of the charge cable into a USB port on your computer or other compatible external device. For a full charge, give the speaker 4-6 hours of charge time.
Pairing a Device with Bluetooth® Your new Bluetooth speaker can wirelessly stream audio from any Bluetooth-enabled. To do so, follow the steps bellow. 1. Put the speaker on your neck. 2. Turn the speaker on. 3. Open the Bluetooth menu of the external device you wish to pair with and initiate a device search. 4. “NAXA NAS-3100” will appear in the list. Select to pair. 5. Should a password prompt appear, enter “0000” to continue pairing. 6.
LED Indicator Light The Bluetooth speaker has an indicator light positioned just above the DC 5V charging port on the side. The light changes to indicate status differences, as stated below. Power On Solid blue light BT Pairing Blinking blue light BT Connected Solid blue light Low Battery Blinking red light Charging Complete No light Charging in Progress Solid red light Using the FM Radio Your speaker can receive FM radio broadcasts. To do so, follow these steps: 1. Turn the speaker on. 2.
Using USB Mode Using Card Mode The speaker can play MP3 files from USB flash drives. To do so, follow these steps: The speaker can play MP3 files from memory cards. To do so, follow these steps: 1. Turn the speaker on. 2. Press the Power button to enter USB mode. 3. Insert the USB flash drive containing your desired audio files into the USB port on the speaker. 4. The speaker will automatically begin playing songs from the inserted USB flash drive. 1. Turn the speaker on. 2.
3. Insert the other end of the included auxiliary cable into the 3.5mm auxiliary port of the external media device (smartphone, MP3 player, computer, tablet, etc.) that you wish to play music from. 4. Select the song you wish to listen to on your external media device and press play. The audio for the selected song will play through the speaker. 5. If you wish to adjust the volume levels on the speaker, hold + to increase the volume or - to decrease the volume.
Warnings and Precautions Important Safety Information triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that shock The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operation and servicing instructions in the literature accompanying the appliance. CAUTION • • • Do not block the ventilation openings or holes. paratus.
9. Ventilation: Slots and openings in the cabinet are provided for ventilation to ensure reliable operation of the product and to protect it from overheating. These openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer instructions have been adhered to. 10.
20. Safety Check: Upon completion of any service or repairs to this product,ask the service technician to perform safety checks to ensure that the product is in proper operating condition. 21. Wall or Ceiling Mounting: The product should be mounted to a wall or ceiling only as recommended by the manufacturer. 22.
Troubleshooting Guide This guide lists common problems and their solutions. Please refer to this guide before requesting service. If you need further assistance, please contact Naxa Technical Support (www.naxa.com/naxa_support/). Symptom There is no power. The device is unable to connect to the speaker. Page 12 Possible Cause Possible Solution The battery is exhausted. Connect the unit to a USB power source to charge it. The speaker hasn’t been turned on.
Support Wireless Version JL 4.0 Output Power 3 Watts x 2 Microphone Yes, built in Playable Media Formats Frequency Response MP3 Input Sources Bluetooth® 120Hz~20KHz 3.5mm AUX audio USB/Memory Card Power Source Rechargeable battery (1500 mAh) USB charge port (DC 5V) Battery Life* If you have problems with your device, please consult the instructions in this manual. Please also visit us on the web at www.naxa.com to get up to the minute news, alerts, and documentation for your device.
