User Manual
Table of Contents In the Box 3 Quick Start Instructions 3 Getting Started Weber iGrill App Battery Replacement Powering On & Off Connecting Disconnecting Mounting Probe Use Probe Wrap Use 4 Using the iGrill Mini Smart LED Proximity Sensor Custom & Preset Alarms Setting Up A Cook Renaming Probes Timer Tool Globe Tool Graph Tool 9 4 5 5 6 6 7 8 9 9 10 10 11 13 13 13 13 Problem Solving 14 Disclaimer 17 Regulations 18
In the Box Inside your iGrill Mini box, you will find: • 1 iGrill Mini • 1 Coin Cell Battery (Installed) • 1 Meat Probe • 1 Colored Probe Indicator (Red) • 1 Probe Wrap • 1 Optional Magnetic Disc • Quick Start Guide Quick Start Instructions 1. Download the Weber iGrill App from the App Store® or Google Play™ Store on one of the following compatible devices: ® • iPhone (4S and later). • iPad (3rd generation and later). • iPad mini (All generations).
5. Clip the iGrill Mini top back into its base. 6. Plug the Pro Meat Probe into the probe port of the iGrill Mini. 7. Press the power button located at the center of the faceplate once, quickly. The display will light up and illuminate white, indicating that the iGrill Mini has powered on. 8. Open the Weber iGrill App to connect to your iGrill Mini. Tap on the iGrill logo in the black toolbar at the top of the app. Select your iGrill Mini from the device manager. 9.
Battery Replacement To replace your iGrill Mini battery, follow these steps: • Separate the iGrill Mini from its base by firmly holding the base with one hand and gently pulling the iGrill Mini top upwards with the other hand. • On the underside of the iGrill Mini, remove the battery door by twisting it counter-clockwise. • Replace the battery with a CR2032 coin cell battery, available at local drugstores in the specialty battery section. • Ensure the battery is in place and replace the battery door.
Connecting To connect your iGrill Mini to your iPhone®, iPad®, iPod touch® or Android™ device follow these steps: • Open Settings. • Tap Bluetooth®. • Set Bluetooth® to On. • While turned on, place your iGrill Mini next to your smart device and open the Weber iGrill App. Your smart device will automatically recognize any available iGrill products and display them in the ‘Available Products’ drop-down. You can view the ‘Available Products’ by tapping the iGrill logo at the top of the app.
• While turned on, place your iGrill Mini next to your smart device and open the Weber iGrill App. Your smart device will automatically recognize any available and previously connected iGrill products. You can view them in the ‘Available Products’ drop-down by tapping the 3 lines or dots at the top, right-hand corner of the screen. • If your iGrill Mini is connected, it will be listed under ‘Connected Devices.
The magnetic base is not designed to withstand high heat and it must be placed on a cool surface. If the surface is too hot to touch, it is too hot for the iGrill Mini base! Probe Use • Meat Probes should always be inserted into the center of the item being cooked for an accurate temperature reading. • When using the Standard Meat Probe, be sure to route the probe wire where it will not be exposed to flames or temperatures exceeding 572°F (300°C). Probes should avoid temperatures below -22°F (-30°C).
The probe should be cleaned by hand with a damp towel or sanitary wipe. The probe is not dishwasher safe. Take precaution not to get the wiring of the probe wet. Be sure to avoid water exposure to the wiring of the probes as well as the area where the wiring and crimp meet the probe. The probe is not waterproof and damage may result from water exposure. The probe should never be submersed in water.
Connection • Solid White: Powering off or reset complete. • Solid Blue: Confirms pairing of new device. • Blinking Blue: Awaiting pairing or no alarm set. Peak Preset • Solid Green: Initial temperature. • Solid Yellow: Target temperature is 15°F (9°C) away. • Solid Orange: Target temperature is 5°F (3°C) away. • Blinking Red: Target temperature reached. • Solid Red: Target temperature reached and alarm acknowledged. Range Preset • Solid Green: Temperature inside range.
If you are having issues hearing the alarms from the Weber iGrill App, try these steps. • Open Settings on your iOS device. • Tap ‘Notification Center.’ • Under the ‘Include’ section, locate and tap ‘Weber iGrill.’ • Enable ‘Notifications’ and ‘Sounds.’ Manage Android™ device alarms: • Open Settings on your device. • Find ’Apps’ and search for the Weber iGrill App. This could be located in your ’Application Manager.’ • Make sure notifications are enabled.
• Tap ‘Set Up Cook’ to the right of a connected probe’s running temperature. • This will bring you to the ‘Set’ cook screen, where you can choose the type of meat you are cooking. • Once the meat is selected, you can ‘Select Your Doneness.’ • You will be directed to the ‘Start Cooking’ screen. Here you can ‘Customize’ your Probe Name or Color, to reflect on your probe dashboard. You can also choose your preferred ‘Probe View.
Renaming Probes A probe can be renamed by tapping on the ‘Probe #’ to the left of the running temperature, then: • Name your probe under ‘Probe Name.’ • Choose a probe color from the ‘Probe Color Indicator’ if needed. • Tap ‘Save’ when done. Timer Tool The timer tool allows users to set up timers. An alert will appear when the timer runs out. To create a new timer: • Tap on the iGrill logo located at the top, right-hand corner of the screen and tap ‘Timers.
Tap on the graph to get a more detailed look of your cook. Below the graph, tap ‘More.’ You will see options to export the graph as a CSV file or clear the history of the graph. Clearing the history of the graph removes all data related to your cook. Problem Solving The following information covers some of the most common troubleshooting issues with the iGrill Mini. If you need further assistance, please review the iGrill Mini FAQ page at support.weber.
• Completely shut down your smart device. • Separate the iGrill Mini from its base by firmly holding the base with one hand and gently pull the iGrill Mini top upwards with the other hand. • While still powered on, remove the iGrill Mini battery cover and press the reset button down with a pin or probe until the light ring illuminates white. • Replace the battery cover, ensuring that the battery is in place. • Power up your smart device and turn Bluetooth® back on.
If you are having intermittent Bluetooth issues with your Android™ device and want to restart Bluetooth from the app: • Tap ‘More’ located at the bottom of the app. • Tap ‘Support.’ • Tap ‘Restart Android™ Bluetooth®’ and ‘Restart’ when prompted and Bluetooth® will restart on your Android™ device and you will have the ability to pair.
I’m experiencing issues with the Weber iGrill App for my Android™ device. The Weber iGrill App requires Android™ version 4.3 or higher to operate. If you are experiencing a problem with the Weber iGrill App for Android™, please try following the steps below to resolve any potential problems on the device. • Make sure the iGrill Mini is paired with your Android™ device via Bluetooth® and a temperature probe is plugged into the unit. • Go to your app manager and quit out of the Weber iGrill App.
Regulations FCC COMPLIANCE STATEMENT: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. INFORMATION TO USER: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules.
Canada – Industry Canada (IC) This device complies with Industry Canada license-exempt RSS Standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Cet appareil est conforme avec Industrie Canada exempts de licence standard RSS (s).
