Broadcast Tools, Inc.
DSC-20, Dual Satellite Receiver Controller Set-up guide
WW1 Network Program and Service Codes:
Programs
Service
Code / ID
#
Strings Comments
Test A / Test B 23 SP C,S,23\#AM C,0\##
CBS 36 / CBS 39 24 SP C,S,24\#AM C,0\##
CBS 37 / CBS 39 25 SP C,S,25\#AM C,0\##
CBS 38 / CBS 39 26 SP C,S,26\#AM C,0\##
DATS 00 / DATS 01 2 SP C,S,2\#AM C,0\##
NBC-E / NEWS EVENTS 17 SP C,S,17\#AM C,0\##
NBC-W / NEWS EVENTS 18 SP C,S,18\#AM C,0\##
CNN-W / ATOM 12 SP C,S,12\#AM C,0\##
MBS-E / NEWS EVENTS 15 SP C,S,15\#AM C,0\##
MBS-W / NEWS EVENTS 16 SP C,S,16\#AM C,0\##
CNN HEADLINE / NEWSLINK 20 SP C,S,20\#AM C,0\##
DATS 06-1 / DATS 09-1 4 SP C,S,4\#AM C,0\##
DATS 07 / DATS 08 14 SP C,S,14\#AM C,0\##
DATS 09-0 / DATS 09-1 3 SP C,S,3\#AM C,0\##
CNN-E / ATOM 11 SP C,S,11\#AM C,0\##
FOX RADIO NET / MISC 2 21 SP C,S,21\#AM C,0\##
DATS 14 / DATS 15 5 SP C,S,5\#AM C,0\##
MARKETWATCH / MISC 6 SP C,S,6\#AM C,0\##
TALK 7 / TALK 8 7 SP C,S,7\#AM C,0\##
CBS 40 / CBS VC 27 SP C,S,27\#AM C,0\##
CBS 41 / CBS 43 8 SP C,S,8\#AM C,0\##
CBS 42 / CBS 44 22 SP C,S,22\#AM C,0\##
CBS 45 / CBS 46 19 SP C,S,19\#AM C,0\##
SPORTS 1 / SPORTS 2 9 SP C,S,9\#AM C,0\##
TRNET / TALK 1 28 SP C,S,28\#AM C,0\##
# Denotes pressing the enter key once ## Denotes pressing the
enter key twice
Use the “AM” Command to control audio flow. Examples are given
below:
AM C,0## Leaves Audio on Port C normal
AM C,1## Puts the Program on the “LEFT” Channel to Both
output channels of Port C
AM C,2## Puts the Program on the “RIGHT” Channel to Both
output channels of Port C
AM C,3## Swaps the Left and Right Channels on Port C
Please check with your NETWORK to verify that they support the
“AM” (Audio Mode) command. Note: We offer three handy
solutions for wiring up the audio and relays on the StarGuide II
& III receivers: 1.) COP; 2.) COA-15, and 3.) COA-37. Please
check our website for more information at www.broadcasttools.com
