Data Sheet

Datenblatt


Erstellungs-Datum December 20, 2013 7:42:14 AM CET
 Katalogstand xx.xx.xxxx / Technische Änderungen vorbehalten 1
Industrial Ethernet
IE-SW-BL05T-5TX
Weidmüller Interface GmbH & Co. KG
Klingenbergstraße 16
D-32758 Detmold
Germany
Fon: [phone]
Fax: [phone]
www.weidmueller.com
General ordering data

Type IE-SW-BL05T-5TX
Order No. 1240850000
Version Network switch, unmanaged, Fast Ethernet,
Number of ports: 5x RJ45, IP 30, -40 °C...+75 °C
GTIN (EAN) 4050118028683
Qty. 1 pc(s).



Weidmüller's BasicLine consists of unmanaged Plug
& Play switches in a robust IP 30 protected aluminium
housing. The equipment can be delivered with Fast
Ethernet and Gigabit Ethernet ports and offers an
economical solution for industrial Ethernet networks.
One variety is fitted with Fast Ethernet and Power-over-
Ethernet ports. All the equipment has been developed for
use in harsh industrial environments and has international
approvals such as CE, cULus, Class I Div. 2 / ATEX and
DNV / GL, and is therefore able to be used in many
international applications.
• Plug & Play switches in a rugged aluminium housing (IP
30)
• Compact design
• Switches for an economical entry solution
• Fast Ethernet versions with 5 and 8 ports
• Models with copper or fibre-optic interface (multimode
and singlemode)
• Full Gigabit Plug and Play switch with 5 ports
• Power-over-Ethernet (PoE) switch with 6 Fast Ethernet
ports, 4 of them PoE+ ports
• Approvals: CE, FCC, cULus, Class I Div. 2 / ATEX, DNV /
GL
