User Documentation

Weidmüller Interface GmbH Co. KG; Klingenbergstraße 16, 32758 Detmold-Germany
Order No
Version: A2C 35* 2551510000
A2C 35-DM* 2551550000
Order No
A2C 35 PE* 2551520000
Block types: Order No
A2C 35 3FT-N-PE* 2551540000
A2C 35 3FT-N* 2552130000
A2C 35 3FT-PE* 2552120000
A2C 35 3FT* 2552100000
A2C 35 3FT-FE* 2552110000
A2C 35 3FT-N-FE* 2552140000
A2C 35 3FT-N-FE-DM* 2552200000
A2C 35 3FT-N-DM* 2552190000
A2C 35 3FT-FE-DM* 2552180000
A2C 35 3FT-DM* 2552170000
Type Order No
AEB 35 SC/1* 1991920000
ZEW 35*
9540000000
TS 35/… acc.to IEC 60715
Plugable Order No
ZQV 35N/2*
2634950000
- Type Wemid
CTI
≥
600
V0
Insulation material:
- Operating temperature range
* in all colours
Cross-connection
Accessories:
end bracket
Terminal rail
TÜV 16 ATEX 7909 U
IECEx TUR 16.0036 U
Notified Body No. of Ex - QA: 0344
Label print on package unit: 0344
Standards:
EN 60079-0:2018 and EN 60079-7:2015 A1:2018
IEC 60079-0: 7th Edition and IEC 60079-7: 5.1th Edition
Modular Terminal Blocks: A2C 35
- Ambient temperature range
In conjunction with:
- Tracking resistance (A) to IEC 60112
- Flammability class to UL 94
- Ambient temperature range
- Ambient temperature range
-60°C…+110°C (insulating material limit)
-60°C…+40°C (for T6 applications)
-60°C…+55°C (for T5 applications)
-60°C…+70°C (for T4 applications)
INSTALLATION INSTRUCTIONS
& CONDITIONS FOR SAFE USE
II 2 GD
Ex eb IIC Gb
Modular TERMINAL Blocks: A- Series
Version: A2C 35; D1395326 Index: 00 Date: 10.2019
1
