User Documentation

Weidmüller Interface GmbH Co. KG; Klingenbergstraße 16, 32758 Detmold-Germany
Order No
Version: AAP13 6 LO LO* 1988260000
AAP13 6 FE-LO* 1988270000
AAP13 1.5 LI LI* 1988280000
Type Order No
AEP AP13* 1990140000
AEB 35 SC/1* 1991920000
TS 35/… acc.to DIN EN 60715
Plugable Order No
ZQV 1.5N/2* 1985410000
ZQV 1.5N/3* 1985480000
ZQV 1.5N/4* 1985490000
ZQV 1.5N/5* 1985500000
ZQV 1.5N/6* 1985510000
ZQV 1.5N/7* 1985520000
ZQV 1.5N/8* 1985540000
ZQV 1.5N/9* 1985560000
ZQV 1.5N/10* 1985580000
- Type Wemid
CTI 600
V0
end plate
end bracket
Terminal rail
Insulation material:
INSTALLATION INSTRUCTIONS
& CONDITIONS FOR SAFE USE
II 2 GD
Ex eb IIC Gb
Modular TERMINAL Blocks: A- Series
- Tracking resistance (A) to IEC 60112
- Flammability class to UL 94
- Ambient temperature range
- Operating temperature range
TÜV 17 ATEX 8030 U
IECEx TUR 17.0015 U
Notified Body No. of Ex - QA: 0344
Label print on package unit: 0344
Standards:
EN 60079-0:2012 + A11 2013 and EN 60079-7:2015
IEC 60079-0: 6th Edition and IEC 60079-7: 5th Edition
- Ambient temperature range
-60°C…+110°C (insulating material limit)
-60°C…+40°C (for T6 applications)
-60°C…+55°C (for T5 applications)
-60°C…+70°C (for T4 applications)
Modular Terminal Blocks: AAP 13…
- Ambient temperature range
Cross-connection
Accessories:
* in all colours
1
