Document of Conformity

Hoersholm, 10 May 2007 Hoersholm, 10 May 2007

Ole Lambertsen

Test Responsible

Poul Villien

Coordinating Manager

Independent Testing - For End User Confidence

Ole Lambertsen

Test Responsible

Poul Villien

Coordinating Manager

Attestation of Conformity

ISO/IEC, EN & TIA/EIA Screened

Class E / Category 6 Four Connector Channel

Weidmüller Interface GmbH&Co.KG

Klingenbergstr. 16

D-32758 Detmold, Germany

Attestation of Conformity No. 107533

This type of Class E / Category 6 screened four connector channel has been tested by 3P Third Party Testing and

complies with the Class E channel requirements of 2 Edition ISO/IEC 11801 and CENELEC EN 50173-1, and the

Category 6 channel requirements of ANSI/TIA/EIA-568-B.2-1. The Attestation of Conformity is valid for the actually

tested channel samples in T568A configuration, with T568B configured patch cords and consisting of the following

Weidmüller components:

Cables: Horizontal Cables, Draka P/N UC900 HS23 Cat.7 S/FTP 4P LSZH

Draka P/N UC900 HS23 Cat.7 S/FTP 2x4P LSZH

Flexible Cable from Patch Cords, P/N IE-C6FP8LD0050A40A40-D

P/N IE-C6FP8LD0075A40A40-D

Qualification Status: Manufacturer Verified

Conn. Hardw.: Keystone Jack, P/N 1962850000 / IE-BI-RJ45-FJ-A

having PCB Marking 033

Back to Back Coupler, P/N 1962840000 / IE-BI-RJ45-C

having PCB Marking 032

Qualification Status: Manufacturer Verified

Patch Cords: 5,0 m and 7,5 m, P/N IE-C6FP8LD0050A40A40-D

P/N IE-C6FP8LD0075A40A40-D

Qualification Status: Manufacturer Verified
