Data Sheet

Datenblatt



Erstellungs-Datum January 15, 2014 9:58:13 AM CET

 Katalogstand xx.xx.xxxx / Technische Änderungen vorbehalten 1

Z-series

ZAP/TW ZDKPE2.5-2

Weidmüller Interface GmbH & Co. KG

Klingenbergstraße 16

D-32758 Detmold

Germany

Fon: +49 5231 14-0

Fax: +49 5231 14-292083

www.weidmueller.com

General ordering data



Type ZAP/TW ZDKPE2.5-2

Order No. 1805960000

Version Z-series, End plate, Partition plate

GTIN (EAN) 4032248280216

Qty. 25 pc(s).



Weidmüller offers users of modular terminals of the Z-

Series a comprehensive range of accessories that render

possible appropriate solutions for all - even non-standard -

tasks.

The accessories must comply with the same quality

standards as the modular terminals themselves.

PAGE 1
Datenblatt Z-series ZAP/TW ZDKPE2.5-2 Weidmüller Interface GmbH & Co. KG Klingenbergstraße 16 D-32758 Detmold Germany Fon: +49 5231 14-0 Fax: +49 5231 14-292083 www.weidmueller.com Weidmüller offers users of modular terminals of the ZSeries a comprehensive range of accessories that render possible appropriate solutions for all - even non-standard tasks. The accessories must comply with the same quality standards as the modular terminals themselves. General ordering data Type Order No.
PAGE 2
Datenblatt Z-series ZAP/TW ZDKPE2.5-2 Weidmüller Interface GmbH & Co. KG Klingenbergstraße 16 D-32758 Detmold Germany Fon: +49 5231 14-0 Fax: +49 5231 14-292083 www.weidmueller.com Technische Daten Dimensions and weights Length Height 72.35 mm 47.45 mm Width Net weight 2 mm 4.97 g -50 °C Storage temperature Continuous operating temp., max. 120 °C Colour Dark Beige UNSPSC eClass 6.2 30-21-18-27 27-14-11-33 Temperatures Operating temperature Continuous operating temp., min.
