Part No. 550-142-027/0508

Model CG Figure 1

Burner

Model

Number

Motor

Size H.P.

Standard Motor

Electrical

Characteristics

Optional Motor

Electrical

Characteristics

Length

(From Mounting

Flange To Label Area

On Burner Front)

Overall

Width

CG10 1/3 120/60/1 240/60/1 22.0 11.7

CG25 3/4 120/60/1

240/60/1,

460/60/3,

575/60/3

29.2 20.9

CG50 2 230/60/1

460/60/3,

575/60/3

29.6 24.4

Burner Speciﬁcation

& Data Sheet

Water & Steam Boilers – Series 2

Beckett

Gas Burners

Models CG10, CG25, CG50

For Gas, Light Oil, & Gas/Light Oil – Fired Burners

Summary of content (4 pages)

PAGE 1
88 Water & Steam Boilers – Series 2 For Gas, Light Oil, & Gas/Light Oil – Fired Burners Burner Specification & Data Sheet Figure 1 Beckett Gas Burners Models CG10, CG25, CG50 Model CG Optional Motor Electrical Characteristics Length (From Mounting Flange To Label Area On Burner Front) Overall Width 120/60/1 240/60/1 22.0 11.7 29.2 20.9 29.6 24.4 Burner Model Number Motor Size H.P.
PAGE 2
Weil-McLain 88 Water and Steam Boilers — Series 2 — For Gas, Light Oil, & Gas/Light Oil-Fired Burners Burner specifications and settings Table 1 Boiler Model Number Burner data Burner Input Gas Mbh Burner Model Number Beckett Burner Part Number For Ordering Approximate Starting Air Settings Low Fire High Fire Starting Positive Head Pressure In Setting Firebox Inches W.C. Burner Motor 3450 Rpm H.P. Pressure Gas Drop Manifold Through Pressure Gas Train (High Inches W.C. Fire) Inches W.C.
PAGE 3
Burner Specification & Data sheet — Beckett Gas Burners Burner specifications and settings (continued) Table 2 Gas train components and flame safeguards Standard Gas Control Components and Sizes in Inches Boiler Model Number Manual Hand Valve (Field Gas Train Connection) Combination Diaphragm Operating Gas Valve And Regulator Safety Gas Valve Manual Checking Gas Valve 488R-488 1 1 1 1 588 & 688 1-1/4 1-1/4 1-1/4 1-1/4 788-988 1-1/2 1-1/2 1-1/2 1-1/2 1088R-1288 1388 2 2 2 2
PAGE 4
Weil-McLain 88 Water and Steam Boilers — Series 2 — For Gas, Light Oil, & Gas/Light Oil-Fired Burners Burner dimensions Figure 2 Beckett model CG10 Figure 3 Beckett models CG25 and CG50 Burner Model Number 4 Dimensions, In Inches A B C D Overall Width Square Flange Width & Height Bolt Circle CG10 11.70 10.0 10.25 4.9 CG25 20.90 12.00 10.25 CG50 24.4 12.00 10.25 E F Maximum Centerline Tube Tube O.D. To End Of Centerline Manifold To Manifold Centerline G H Overall Length (Max.
