TABLE OF CONTENTS WARRANTY FEATURES & OPERATING CONTROLS PRECAUTIONS & GENERAL INFORMATION AGENCY LISTING INFORMATION INSTALLATION OPERATION MAINTENANCE INSTRUCTIONS CLEANING INSTRUCTIONS TROUBLESHOOTING SUGGESTIONS WIRING DIAGRAM EXPLODED VIEW & PARTS LIST PARTS & SERVICE CUSTOMER SERVICE DATA xi 2 3 3 4 6 7 8 10 10 11 12 13 INTRODUCTION Thank You for purchasing this Wells Bloomfield appliance.
FEATURES & OPERATING CONTROLS A. INFINITE SWITCH IMPORTANT: DO NOT LEAVE ON “PREHEAT” Unit may cycle on hi-limit control, leading to premature failure of the hi-limit control device. 1. On INFINITE SWITCH CONTROLLED warmers, power is applied to the heating element based on the control knob position, which varies the duty cycle of the heating element. 2. The desired temperature is controlled by rotating the TEMPERATURE CONTROL KNOB.
PRECAUTIONS AND GENERAL INFORMATION This appliance is intended for use in commercial establishments only. This appliance is intended to hold pre-heated food for human consumption. No other use is recommended or authorized by the manufacturer or its agents. Operators of this appliance must be familiar with the appliance use, limitations and associated restrictions. Operating instructions must be read and understood by all persons using or installing this appliance.
INSTALLATION NOTE: DO NOT discard the carton or other packing materials until you have inspected the appliance for hidden damage and tested it for proper operation. Refer to SHIPPING DAMAGE CLAIM PROCEDURE on the inside front cover of this manual. WARNING: RISK OF INJURY Installation procedures must be performed by a qualified technician with full knowledge of all applicable electrical and plumbing codes. Failure can result in personal injury and property damage.
INSTALLATION 4. For “top-mounted” warmers (i.e. warmers mounted from above the counter top): a. Verify that provided sealants are applied to the underside of the warmer top flange prior to setting the unit into the cutout. b. After installation, verify that the tabs on the Wellsloks are turned out to lock the warmer into the counter c. Apply a thin bead of food-grade silicone sealant around the flange to seal it to the counter. d.
OPERATION CAUTION: HOT SURFACE Exposed surfaces can be hot to the touch and may cause burns. CAUTION: SHOCK HAZARD DO NOT splash or pour water onto control panel or wiring. Always use an inset. DO NOT place food directly into the warmer. Always pour hot water into the warmer before it is preheated. DO NOT pour water into a dry, heated warmer. This may damage the unit. Stir thick food items frequently to keep food heated uniformly. Keep insets covered to maintain food quality and temperature. 1.
MAINTENANCE INSTRUCTIONS CARE OF STAINLESS STEEL Stainless steel is a marvelous material: strong, lustrous and low maintenance. With a minimum of care, it will normally retain its beauty and durability for the life of the equipment. In some applications, however, special care is required in order to maintain stainless steel’s special properties. External components, such as cabinets and control panels, are finished with a grain pattern.
CLEANING INSTRUCTIONS CAUTION: SHOCK HAZARD Do NOT splash or pour water into or over any control panel or wiring. CAUTION: SHOCK HAZARD DAILY CLEANING INSTRUCTIONS PREPARATIONS: Turn control knob(s) to OFF. Allow warmer to cool before proceeding. Remove any insets, pans and/or adapter tops ( if used). Drain or remove water from well if used for wet operation. FREQUENCY: Minimum - daily.
CLEANING INSTRUCTIONS WEEKLY CLEANING INSTRUCTIONS CAUTION: PREPARATIONS: Remove any insets, pans and/or adapter tops. Drain or remove water from well if used for wet operation. FREQUENCY: Weekly, or whenever lime or scale is seen accumulating on the sides of the warmer pans. TOOLS: Commercial Delime Cleaner Plastic Scouring Pad Clean Cloth or Sponge 1. Add water to pans until water is at normal operating level (1” - 1 1/2” deep) or covers accumulated scale. 2.
TROUBLESHOOTING SUGGESTIONS SYMPTOM POSSIBLE CAUSE SUGGESTED REMEDY No power to warmer Circuit breaker off or tripped Reset circuit breaker Warmer will not heat Temperature control not set Set control to desired temperature Wet insulation Verify flange-to counter seal is sound, or reseal with food-grade silicone sealant Pan leaking or other internal damage Contact your Authorized Wells Service Agency for repairs Internal damage Contact your Authorized Wells Service Agency for repairs Mineral
EXPLODED VIEW & PARTS LIST 50374 51877 (pk 10) 50397 (pk 6) 50398 (208/240V) 55741 MOD-400 55707 55741 make from 56196 (150' roll) make from 56050 (150' roll) 21709 53201 MOD-400D 55004 53201 50131 61974 57809 57806 50385 21709 50562 (240V) 50570 (120V) OFF HI LO WELLS 3 7 55742 6 55609 11 5 55742 4 MOD-400DM 2 M012C.04 2M-308032 Owners Manual for Four-Well Inf.Sw.
PARTS & SERVICE Always use an inset. DO NOT place food directly into the warmer pan. DESCRIPTION PART NO. ADAPTERS & INSETS ADAPTER TOP, convert 12” x 20” warmer to hold two 7 qt. insets 21502 ADAPTER TOP, convert 12” x 20” warmer to hold two 4 qt. and two 2½ qt 21503 ADAPTER TOP, convert 12” x 20” warmer to hold three 4 qt. insets 21616 ADAPTER TOP, convert 12” x 20” warmer to hold one 7qt. and one 4 qt. 21618 ADAPTER TOP, convert 12” x 20” warmer to hold four 2½ qt. insets 21623 2½ QT.
PARTS & SERVICE DESCRIPTION PART NO. ACCESSORIES 6 oz.
