MODEL 3625 4-1/2" MINI CIRCULAR SAW 766B For replacement parts visit WENPRODUCTS.COM 5005389 IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions.
TABLE OF CONTENTS Specifications................................................................................... 2 Introduction..................................................................................... 3 General Safety Rules........................................................................ 4 Specific Safety Rules for the Mini Circular Saw................................ 6 Electrical Information.......................................................................
INTRODUCTION Thanks for purchasing the WEN Mini Circular Saw. We know you are excited to put your tool to work, but first, please take a moment to read through the manual. Safe operation of this tool requires that you read and understand this operator’s manual and all the labels affixed to the tool. This manual provides information regarding potential safety concerns, as well as helpful assembly and operating instructions for your tool. SAFETY ALERT SYMBOL: Indicates danger, warning, or caution.
GENERAL SAFETY RULES Safety is a combination of common sense, staying alert and knowing how your item works. SAVE THESE SAFETY INSTRUCTIONS. WARNING: Read and understand all warnings, cautions and operating instructions before using this tool. Failure to follow all instructions listed below may result in personal injury, electric shock, fire and/or tool damage. WORK AREA SAFETY 1. Keep work area clean and well lit. Cluttered or dark areas invite accidents. 2.
GENERAL SAFETY RULES 5. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. 6. Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. 7. If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used.
SPECIFIC RULES FOR THE MINI CIRCULAR SAW WARNING: Do not let comfort or familiarity with the product replace strict adherence to product safety rules. Failure to follow the safety instructions may result in serious personal injury. 1. TOOL PURPOSE. This circular saw is designed to cut through softwood only. Cutting other materials could result in fire, injury, or damage to the workpiece.
SPECIFIC RULES FOR THE MINI CIRCULAR SAW full stop before reaching for loose materials or setting the tool down. 12. REPLACING THE SAW BLADE. Check the blade for chipped or broken teeth. Do not use dull or damaged blades. Unshaped or improperly set blades produce narrow kerf, causing excessive friction, blade binding, and kickback. Always use blades with correct size and arbor holes. Blades that do not match the mounting hardware of the saw will run eccentrically, causing a loss of control. 13.
SPECIFIC RULES FOR THE MINI CIRCULAR SAW LASER SAFETY ATTENTION: LASER RADIATION. CLASS 2 LASER. DO NOT STARE INTO THE BEAM. 1. Do not look directly into the laser beam with unprotected eyes. Never look into the path of the beam. 2. Never point the laser beam towards reflective surfaces. Never point the laser towards people or animals. Even a laser beam with a low output can cause damage to the eyes. 3. Never open the laser module as unexpected exposure to the beam can occur.
ELECTRICAL INFORMATION DOUBLE-INSULATED TOOLS The tool’s electrical system is double insulated where two systems of insulation are provided. This eliminates the need for the usual three-wire grounded power cord. Double insulated tools do not need to be grounded, nor should a means for grounding be added to the product. All exposed metal parts are isolated from the internal metal motor components with protecting insulation.
KNOW YOUR MINI CIRCULAR SAW UNPACKING With the help of a friend or trustworthy foe, carefully remove the saw from the packaging. Make sure to take out all contents and accessories. Do not discard the packaging until the saw is completely assembled. TOOL PURPOSE This circular saw is designed to make quick, versatile cuts through soft wood. Refer to the diagram below to become familiarized with the parts and controls of your Mini Circular Saw.
ASSEMBLY & ADJUSTMENTS INSTALLING/REPLACING THE SAW BLADE (FIGS. 1 & 2) Use saw blades with 4-1/2 inch (115 mm) diameter and 3/8 inch (10 mm) arbor. Do not use a blade that does not match the diameter or arbor size. The pre-installed blade has a body that is 1.2 mm thick and theeth that are 1.8 mm thick . Do not use a blade that is thicker than the included blades, as this will prevent the arbor screw from properly securing the blade.
ASSEMBLY & ADJUSTMENTS SETTING THE DEPTH OF CUT (FIG. 4) Before making a cut, it is important to set the correct cutting depth. The saw’s maximum cutting depth at 90° is 1-11/16 inch (43 mm), at 45° it is 1-1/8" (28 mm). We recommend adjusting the cutting depth about 1/16 inch (2 mm) deeper than the thickness of the material. To adjust the cutting depth, you can either refer to the depth scale, or the edge of the workpiece. Using the Depth Scale: 1. Unplug your mini circular saw from the power source.
ASSEMBLY & ADJUSTMENTS USING THE LASER (FIG. 6) The laser located on the top of your saw can also be used to indicate the line of cut. Unscrew the laser cover and install the two AG13 batteries. Securely replace the laser cover. Switch the laser ON and align the laser line with your cutting guideline. Laser Switch Laser WARNING: Do not look directly into the laser beam with unprotected eyes. See page 8 for important rules regarding laser safety. Fig. 6 INSTALLING THE RIP FENCE (FIG.
ASSEMBLY & ADJUSTMENTS ADJUSTING THE BLADE BEVEL (FIG. 10) Bevel your mini circular saw blade from 45° to 90° to cut your workpiece on an angle. The saw’s maximum cutting depth at 90° is 1-11/16 inch (43 mm), at 45° it is 1-1/8" (28 mm). Be sure to set your saw to the proper depth for the angle you are using (see Page. 12). Bevel Scale 1. Unplug your mini circular saw from the power source. 2. Flip up the bevel locking knob to loosen it. 3.
OPERATION PREPARING FOR OPERATION 1. Prepare the work space and position power cords away from the cutting area. Connect your saw to a dust extraction system (see Page. 13). 2. Ensure that the saw blade is sharp. Set the correct depth of cut for your workpiece (see Page. 12). 3. Draw a guideline along the desired path of the cut on the workpiece surface. 4.
MAINTENANCE WARNING: To avoid accidents, turn OFF and unplug the tool from the electrical outlet before cleaning, adjusting, or performing any maintenance or lubrication work. WARNING: Any attempt to repair or replace electrical parts on this tool may be hazardous. Servicing of the tool must be performed by a qualified technician. When servicing, use only identical WEN replacement parts. Use of other parts may be hazardous or induce product failure.
TROUBLESHOOTING GUIDE WARNING: Stop using the tool immediately if any of the following problems occur. Repairs and replacements should only be performed by an authorized technician. For any questions, please contact our customer service at (800) 232-1195, M-F 8-5 CST or email us at techsupport@wenproducts.com. PROBLEM Motor does not start Ineffective Cutting CAUSE SOLUTION Power cord damaged or not properly plugged in. Check the power cord, extension cord, power plug and the power outlet.
EXPLODED VIEW & PARTS LIST 18
EXPLODED VIEW & PARTS LIST No. Part No.
EXPLODED VIEW & PARTS LIST 20 No. 49 50 51 52 53 54 Part No. 3625-049 3625-050 3625-051 3625-052 3625-053 3620-057 Description Blade Arbor Screw Outer Flange Screw St4.2x12 Lever For Blade Cover Left Label Left Housing Screw For Reset Spring Reset Spring Switch Locking Button Switch Trigger Spindle Lock Spring Switch Terminal Insert, 4.8x0.8 Qty.
WARRANTY STATEMENT WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN consumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase.
