8-GAUGE 2-INCH 2-IN-1 NAILER Model # 61718 For replacement parts visit WENPRODUCTS.COM bit.ly/wenvideo IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions.
TABLE OF CONTENTS 2 3 4 7 8 10 12 13 14 16 Technical Data Safety Introduction Safety Rules Know Your Nailer Preparation and Adjustments Operation Maintenance Toubleshooting Exploded View and Parts List Warranty Statement TECHNICAL DATA Model Number: Minimum Operating Pressure: Maximum Operating Pressure: Air Inlet: Air Consumption per Nail: Nail Type: Nail Length: Staple Type: Staple Length: Magazine Capacity: Weight: 2 61718 60 PSI 100 PSI 1/4˝- 18 NPT 0.
SAFETY INTRODUCTION Hello! Thank you for purchasing the WEN 2-in-1 Nailer & Stapler. Safe operation of this pneumatic tool requires that you read and understand this operator’s manual and all labels affixed to the tool. Safety is a combination of common sense, staying alert, and knowing how your tool works. The purpose of the following safety symbol is to attract your attention to possible dangers. We don’t want any of our beloved WEN customers accidentally injuring themselves.
SAFETY RULES Safety is a combination of common sense, staying alert and knowing how your item works. SAVE THESE SAFETY INSTRUCTIONS. WARNING: To avoid mistakes and serious injury, do not use your tool until the following steps have been read and understood 1. READ and become familiar with this entire instruction manual, no matter how boring it may be. LEARN the tool’s applications, limitations, and possible hazards. 2. ALWAYS keep your work area clean, uncluttered, and well lit.
SAFETY RULES 13. USE ONLY clean dry and regulated air. Condensation from an air compressor can rust and damage the internal workings of the tool. 14. DO NOT USE BOTTLED GASES to power this tool. Bottled compressed gases including but not limited to oxygen, carbon dioxide, nitrogen, hydrogen, propane, acetylene or air are not for use with pneumatic tools. Never use combustible gases or any other reactive gas as a power source for this tool. DANGER OF EXPLOSION AND/OR SERIOUS PERSONAL INJURY MAY RESULT. 15.
SAFETY RULES 28. KEEP FACE AND BODY PARTS away from the back of the tool cap when working in restricted areas. Sudden recoil can result in impact to the body, especially when nailing into hard or dense material. 29. DO NOT DRIVE FASTENERS near the edge of your work material. The workpiece may split, causing the fastener to ricochet, injuring you or a bystander. Be aware that the nail may follow the grain of the wood, causing it to protrude unexpectedly from the side of the work material.
KNOW YOUR NAILER Carefully unpack the tool from the packaging. Check all components and compare against the graph below. If any part is damaged or missing, please contact our customer service at (800) 232-1195, M-F 8-5 CST or email us at techsupport@wenproducts.com.
PREPARATION AND ADJUSTMENTS LUBRICATING THE TOOL (Fig. 1) This tool requires lubrication before each use (especially the first use). Proper lubrication is the owner’s responsibility. Failure to lubricate the tool properly will dramatically shorten the life of the tool and void the warranty. NOTE: The in-line oiler is a convenient way to provide oil to the tool. If an in-line oiler is installed, manual lubrication through the air inlet is not required. Oil 1.
PREPARATION AND ADJUSTMENTS LOADING THE FASTENERS WARNING: Always load the fasteners after connecting the tool to its air supply. Otherwise, unwanted misfires may occur during connection. Never aim the tip towards yourself or others. 1. Depress the magazine lock and pull out the movable magazine fully (Fig 3). Fig. 3 2. Hold the nailer with the magazine to your side. Make sure the firing tip is directed away from yourself or others. 3.
OPERATION WARNING: Before each use, check the nail, compressed air connections and air lines. If any parts are missing or damaged, do not operate this tool until the parts are repaired and replaced. Failure to do so could possibly result in a serious personal injury. ADJUSTING THE DEPTH ADJUSTMENT WHEEL The nailer is equipped with a depth adjustment wheel (Fig. 8) for setting the penetration depth of the fasteners. 1. Turn the wheel clockwise to increase the firing depth (wheel moves downwards). 2.
OPERATION DRIVING MODE This nailer follows a single driving mode, which means only one nail will be driven at a time. There is no bump-fire mode for this nailer. This type of driving mode minimizes the chances of accidental firing and maximizes safety. The nailer is equipped with a safety bracket that needs to be activated before pulling the trigger in order to drive a fastener. The driving process can only be triggered in the following sequence of activation: 1.
MAINTENANCE WARNING: Disconnect tool from air supply and empty fasteners from the magazine before performing any cleaning or maintenance. LUBRICATION Routine lubrication of the tool is required for best performance. If tool is used without an in-line oiler, place 3 to 4 drops of pneumatic tool oil into the air inlet of the tool at the beginning of each workday. This will ensure the moving components are finely lubricated. CLEANING Keep tools clean for better and safer performance.
TROUBLE SHOOTING WARNING: Stop using the tool immediately if any of the following problems occur or risk serious personal injury. Repairs and replacements should only be performed by authorized personnel at a certified WEN service center. Problem Air leaking at trigger area Common Causes 1. O-ring in trigger valve is damaged. 2. Trigger valve head is damaged. 3. Trigger valve stem, seal or O-ring is damaged. Air leaking between Damaged piston O-ring or bumper. body and drive guide Air leaking between 1.
EXPLODED VIEW AND PARTS LIST 14
EXPLODED VIEW AND PARTS LIST No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 Parts No.
LIMITED TWO YEAR WARRANTY WEN Products is committed to build tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN consumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase.
