3 X 18 INCH BELT SANDER Model # 6318 bit.ly/wenvideo 3104259 IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use your tool properly and for intended purpose, you will enjoy years of safe, reliable service.
TABLE OF CONTENTS 2 3 4 6 7 8 9 10 12 13 Technical Data General Safety Rules Specific Safety Rules For Sander Electrical Information Know Your Belt Sander Preparation and Adjustment Operation Exploded View and Parts List Maintenance Warranty TECHNICAL DATA Model Number: Motor: Speed: Belt Size: Weight: Dimensions: 2 6318 120 V, 60 Hz, 6A 820 feet per minute 3 x 18 in. 5.5 lbs 10 x 6 x 5.5 in.
GENERAL SAFETY RULES Safety is a combination of common sense, staying alert and knowing how your item works. SAVE THESE SAFETY INSTRUCTIONS. WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and serious injury. To avoid mistakes and serious injury, do not plug in your tool until the following steps have been read and understood. WORK AREA SAFETY 1. Keep work area clean and well lit.
GENERAL SAFETY RULES 2. Check power tool for damaged parts. Check for misalignment of moving parts, jamming, breakage, improper mounting, or any other conditions that may affect the tool’s operation. Do not use the power tool if the switch does not turn ON/OFF. Any part that is damaged should be properly repaired or replaced before use. 3. Do not force the tool to do a job for which it was not designed.
SPECIFIC RULES FOR THE SANDER 4. Securing the Workpiece Never hold the workpiece in your hand or across your legs. Small workpieces must be adequately secured so that the rotating belt doesn’t pick them up during the forward motion of the sander. Unstable support causes the belt to bind, resulting in a loss of control and possible injury. 5.
ELECTRICAL INFORMATION GROUNDING INSTRUCTIONS IN THE EVENT OF A MALFUNCTION OR BREAKDOWN, grounding provides the path of least resistance for an electric current and reduces the risk of electric shock. This tool is equipped with an electric cord that has an equipment grounding conductor and a grounding plug. The plug MUST be plugged into a matching outlet that is properly installed and grounded in accordance with ALL local codes and ordinances. DO NOT MODIFY THE PLUG PROVIDED.
KNOW YOUR BELT SANDER 1 5 6 2 7 8 9 3 4 1. Belt Sander Casing 2. Front Handle 3. Tracking Adjustment Knob 4. Drive Belt Cover 5. Dust Extraction Outlet 6. Rear Handle 7. Continuous Running Switch 8. On/Off Switch 9. Sawdust Collector Bag 10. Belt Tensioning Lever 11.
PREPARATION AND ADJUSTMENT CHOOSING SANDING BELTS Sanding belts come in different grades from rough through to smooth. Select the grade required for the particular job. Refer to the table below for the type and applications of different grades. Grit Type Up to 60 Very coarse 80 to 100 Course 120 to 150 Medium Course 180 to 220 Fine 240 or Higher Very Fine Applications Rough work, removing hard paint, shaping wood. Removing paint, smoothing rough surfaces (e.g. unplaned wood).
OPERATION CAUTION: Never cover the air vents. They must always be open for proper motor cooling. Make sure that the work piece is free of nails and other foreign objects that could tear the abrasive belt. 1. Hold the machine firmly with both hands and assume a balanced position. 1 2. Pull the trigger switch and allow the motor to reach full speed. For continuous operation, press in the power lock-on button located on the side of the handle (Fig. 4 - 1). 3. Hold the machine parallel to the work piece.
EXPLODED VIEW AND PARTS LIST Number Part Number 1 6318-001 2 6318-002 3 6318-003 4 6318-004 5 6318-005 6 6318-006 7 6318-007 8 6318-008 9 6318-009 10 11 6318-010 12 13 6318-013 14 6318-014 15 6318-015 16 6318-016 17 6318-017 18 6318-018 19 6318-019 20 21 6318-020 22 6318-022 23 24 6318-023 25 6318-025 26 6318-026 27 28 29 30 6318-027 31 32 33 34 35 6318-035 10 Description Power Cord Cord Sleeve Screw Cord Clamp Capacitors Switch Support Bracket Screw Label Right housing Middle Housing Ceramic Block Retain
EXPLODED VIEW AND PARTS LIST 11
MAINTENANCE SERVICE: Preventive maintenance performed by unauthorized personnel may result in misplacing of internal wires and components, possibly causing a serious hazard. We recommend that all tool service be performed by an authorized WEN service station. CLEANING: Ventilation openings and switch levers must be kept clean and free of foreign matter. The tool may be cleaned most effectively with compressed dry air. Do not attempt to clean these components by inserting pointed objects through openings.
LIMITED TWO YEAR WARRANTY WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN consumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase.
