Use and Care Manual

EXPLODED VIEW AND PARTS LIST
Item # Stock # Description Qty
1 6550-101 Screw 4
1A 6550-101A Flat washer 6 4
2 6550-102 Left Cap 1
3 6550-103 Cotter Pin 2
4 6550-104 Roller 1
5 6550-105 Handle Assembly 1
6 6550-106 Right Cap 1
7 6550-107 Grip 2
8 6550-108 Elevating Nut (RH) 2
9 6550-109 Left Side Cover 1
10 6550-110 Bolt 9
11 6550-111 Spacer 1
12 6550-112 Elevating Screw (LH) 1
13 6550-113 Column 4
14 6550-114 Screw 3
15 6550-115 Guide 2
16 6550-116 Table 1
17 6550-117 Elevating Screw (RH) 1
18 6550-118 Extension Table Assembly 2
19 6550-119 Table Support 4
20 6550-120 Base 1
Item # Stock # Description Qty
21 6550-121 Plate 3
22 6550-122 Set Screw 3
23 6550-123 Nut 4
24 6550-124 Adjustment Screw 4
25 6550-125 Lock Washer 10 4
26 6550-126 Bolt 4
27 6550-127 Screw with washer 8
28 6550-128 Screw 4
29 6550-129 Bushing 4
30 6550-130 Wavy Washer 4
31 6550-131 Shaft 1
32 6550-132 Support 2
33 6550-133 Retaining Ring 2
34 6550-134 Bevel Gear 4
35 6550-135 Elevation Screw Bearing Assembly 2
36 6550-136 Right Side Cover 1
37 6550-137 Wrench 1
38 6550-138 Magnet 2
39 6550-139 Elevating Nut (LH) 2
16
Item # Stock # Description Qty
1 6550-201 Dust Exhaust Port 1
2 6550-202 Thumb Screw 2
3 6550-203 Set Screw 2
4 6550-204 Motor Assembly 1
5 6550-205 Screw 4
6 6550-206 Push Plate 1
7 6550-207 Dust Chute 1
8 6550-208 Thumb Screw 2
9 6550-209 Chute Plate 1
10 6550-210 Switch w/Key 1
11 6550-211 Brush Holder 2
12 6550-212 Brush (Set of 2) 1
13 6550-213 Brush Cap 2
14 6550-214 Retaining Ring 3
15 6550-215 Chain 2
16 6550-216 Sprocket 4
17 6550-217 Spacer 1
18 6550-218 Bolt 4
19 6550-219 Gearbox Assembly 1
20 6550-220 Pinion 1
21 6550-221 Ball Bearing 6203ZZ 2
22 6550-222 Cover 1
23 6550-223 Set Screw 1
24 6550-224 Screw 2
25 6550-225 Washer 5 2
26 6550-226 Rollercase 1
27 6550-227 Screw with Washer 1
28 6550-228 Cord Clamp 1
29 6550-229 Screw with Washer 2
30 6550-230 Belt Guard 1
31 6550-231 Plunger 1
Item # Stock # Description Qty
32 6550-232 Spring 1
33 6550-233 Set Screw 4
34 6550-234 Cutterhead Lock 1
35 6550-235 Spacer 1
36 6550-236 Screw 1
37 6550-237 Flat Washer (N) 8 1
38 6550-238 Bolt 1
39 6550-239 Cutterhead 1
40 6550-240 Key 5 x 5 x 12 1
41 6550-241 Rod 1
42 6550-242 Blade (set of 2) 1
43 6550-243 Locking Bolt 12
44 6550-244 Gib 2
45 6550-245 Nut 1
46 6550-246 Belt 1
47 6550-247 Cutterhead Pulley 1
48 6550-248 Bolt 11
49 6550-249 Motor Pulley 1
50 6550-250 Bearing Retainer 1
51 6550-251 RH Retainer 2
52 6550-252 Bearing Block 4
53 6550-253 RH Spring 2
54 6550-254 Outfeed Roller 1
55 6550-255 LH Spring 2
56 6550-256 Infeed Roller 1
57 6550-257 LH Retainer 2
58 6550-258 Screw 2
59 6550-259 Depth Indicator 1
60 6550-260 Circuit Breaker 1
FIGURE 13 - BASE
FIGURE 14 - ROLLER CASE
