Computer Drive Specification Sheet
WD Scorpio Blue
-2-
Specifications
1 TB 1 TB 750 GB 640 GB 500 GB 500 GB
Model number WD10JPVT WD10TPVT WD7500BPVT WD6400BPVT WD5000LPVT WD5000BPVT
Interface SATA 3 Gb/s SATA 3 Gb/s SATA 3 Gb/s SATA 3 Gb/s SATA 3 Gb/s SATA 3 Gb/s
Formatted capacity
1
1,000,204 MB 1,000,204 MB 750,156 MB 640,135 MB 500,107 MB 500,107 MB
User sectors per drive 1,953,525,168 1,953,525,168 1,465,149,168 1,250,263,728 976,773,168 976,773,168
Ad vanced F ormat (AF) Yes Yes Yes Yes Yes Yes
Form factor 2.5-inch 2.5-inch 2.5-inch 2.5-inch 2.5-inch 2.5-inch
RoHS compliant
2
Yes Yes Yes Yes Yes Yes
Performance
Data transfer rate (max)
Buffer to host
Host to/from drive (sustained)
3 Gb/s
144 MB/s
3 Gb/s
124 MB/s
3 Gb/s
138 MB/s
3 Gb/s
151 MB/s
3 Gb/s
147 MB/s
3 Gb/s
136 MB/s
Cache (MB) 888888
Average latency (ms) 5.5 5.7 5.5 5.5 5.5 5.5
Rotational speed (RPM) 5400 5200 5400 5400 5400 5400
Average drive ready time (sec)<3.5844<3.54
Reliability/Data Integrity
Load/unload cycles
4
600,000 600,000 600,000 600,000 600,000 600,000
Non-recoverable read errors
per bits read
<1 in 10
14
<1 in 10
14
<1 in 10
14
<1 in 10
14
<1 in 10
14
<1 in 10
14
Limited warranty (years)
5
222222
Power Management
5VDC ±10% (A, peak) 0.900 0.985 0.975 0.950 0.900 0.950
Average power requirements (W)
Read/Write
Idle
Standby/Sleep
1.4
0.59
0.18
1.7
0.75
0.20
1.6
0.65
0.20
1.6
0.65
0.20
1.4
0.55
0.13
1.6
0.65
0.20
Environmental Specifications
6
Temperature (°C)
Operating
Non-operating
0 to 60
-40 to 65
0 to 60
-40 to 65
0 to 60
-40 to 65
0 to 60
-40 to 65
0 to 60
-40 to 65
0 to 60
-40 to 65
Shock (Gs)
Operating (2 ms, read)
Non-operating
400
1000 (2 ms)
350
1000 (2 ms)
350
1000 (2 ms)
350
1000 (2 ms)
400
1000 (2 ms)
350
1000 (2 ms)
Acoustics (dBA)
7
Idle
Seek (average)
22
25
24
25
22
25
22
25
17
22
22
25
Physical Dimensions
Height (in./mm, max)
8
0.374/9.50 0.49/12.50 0.374/9.50 0.374/9.50 0.27/6.8 0.374/9.50
Length (in./mm, max) 3.94/100.20 3.94/100.20 3.94/100.20 3.94/100.20 3.94/100.20 3.94/100.20
Width (in./mm, ± .01 in.) 2.75/69.85 2.75/69.85 2.75/69.85 2.75/69.85 2.75/69.85 2.75/69.85
Weight (lb./kg, ± 10%) 0.27/0.11 0.34/0.15 0.34/0.15 0.22/0.10 0.20/0.09 0.22/0.10
1
As used for storage capacity, one megabyte (MB) = one million bytes, one gigabyte (GB) = one billion bytes, and one terabyte (TB) = one trillion bytes. Total accessible capacity varies depending on operating environment. As used for buffer or cache, one megabyte (MB) = 1,048,576 bytes.
As used for transfer rate or interface, megabyte per second (MB/s) = one million bytes per second, and gigabit per second (Gb/s) = one billion bits per second. Effective maximum SATA 3 Gb/s transfer rate calculated according to the Serial ATA specification published by the SATA-IO
organization as of the date of this specification sheet. Visit www.sata-io.org for details.
2
WD hard drive products manufactured and sold worldwide after June 1, 2006, meet or exceed Restriction of Hazardous Substances (RoHS) compliance requirements as mandated by the RoHS Directive 2011/65/EU.
3
Maximum burst rate running the Mode 5 Ultra ATA transfer mode.
4
Controlled unload at ambient condition.
5
The term of the limited warranty may vary by region. Visit support.wdc.com/warranty for details.
6
No non-recoverable errors during operating tests or after non-operating tests.
7
Sound power level.
8
The WD10TPVT model is 12.5 mm high and may not be compatible with all notebook systems. Consult system specifications for maximum allowable drive height before attempting to install.
