Spec Sheet

KitchenAid Model: KCGS556ESS
36'' 5-Burner Gas Cooktop
Color Stainless Steel
Product Description
If you love to experiment and push culinary limits, you'll appreciate
the power and versatility of this 36-inch cooktop. Five individual
burners includes a powerful 20K BTU Dual Ring Burner that is
among the most powerful in the industry. The eye-catching design
includes Multi-Finish Knobs and the scratch-resistant CookShield
Finish help protect the surface against stains that may occur with
high-temperature cooking.
Specifications
Refinement KAD
20K BTU Dual-Ring Burner 20K BTU Dual-Ring Burner
Cookshield Finish Cookshield Finish
Certifications
Prop 65
CALIFORNIA
RESIDENTS ONLY -
WARNING: Cancer and
Reproductive Harm -
www.P65Warnings.ca.gov
Appearance
Digital Display No
GDS
Product Type EA
UDEX 1100400623
Dimensions
Cutout Depth 19-13/16
Cutout Width 35-3/16
Maximum Height 4-5/16
Cutout Height 5-1/4
Height 3-11/16
Width 36.0
Depth 21.0
Cutout Depth Max 20.0
Controls
Location of Controls Front
Infinite Heat Controls Yes
Dimensions
Gross Weight 69.000
Refinements
Features 20K BTU Dual-Ring Burner
Even-Heat Melt Burner
Cookshield Finish
ADA Compliant
Cooktop Details
Left Rear Element-Burner Simmer
Center Rear Element-Burner 20,000 BTU
Left Front Element-Burner Burner
Cooktop Element Style Sealed Burner
Right Rear Element-Burner Burner
Left Rear Element-Burner 6000 BTU
Cooktop Surface Material Stainless Steel
Left Front Element-Burner 10,000 BTU
Number of Grates 3
Heating Element On No
Automatic Pan Detection No
Number of Cooking Element- 5
Power Outage Compatible Yes
Downdraft Vent No
Hot Surface Indicator Light No
Ignition Type Direct Spark Ignition
Grate Details Dishwasher Safe
Matte Finish
Continuous
Cast Iron Grates
Right Front Element-Burner 10,000 BTU
Configuration and Overview
Size 36
Cooktop Type Standard
Fuel Type Gas
LP Convertible Yes - Kit Included
Installs Over Built-In Oven Yes
Power Boost No
ADA Compliant ADA Height and Side Reach
UL UL
