Spec Sheet

REMOTE FAN MOTOR - INLINE UnIT
Haus Group Australia Pty Ltd - 03 8593 9600 - www.whispair.com.au
Ducting 200mm Acoustic (PVC Coated) Flexi Ducting
Five (5) Metre Length Supplied
Duct Clamps Dia. 200mm (Stainless Steel) - 4X Units Supplied
Finish
Motor Mounting Inline - Through Wall or Eave
Product Features
Extraction Levels
Available
Model: IL.800
Lite - 800 m3/hr
(222 L/s @ 50pa)
Model:
IP.1140
Pro - 1140 m3/hr
(317 L/s @ 50pa)
High Grade FR ABS Plastic
Colour: Shale Grey
Inline Motor Unit
Inline Motor Unit
External View
Inline Motor Unit
Internal View
30
70
314
200
390
12
159
363.5
143.5 125
268.5
Fan Power Supply Cable Length: Three (3) Metres
Sound Pressure Level IL.800: 52dB(A)* when operating at ‘Boost’ speed
IP.1140: 58dB(A)* when operating at ‘Boost’ speed
* Outside Level @ 1M & System Pressure 50pa
Inlet Cone &
Flow Grid
Dimensioned Drawings
Vent Dia. 220mm Aluminium with ne mesh liner and
Powder Coat Finish - Colour: White - 1X Unit Supplied
