User’s Manual and Laser Safety Guide www.wickedlasers.
FOREWORD First and foremost, we are laser enthusiasts. We desire nothing more than to achieve perfection in our craft. For us, pushing the limits of technology is part of our daily routine. It’s only impossible if we don’t try. As we continue to advance in our search for perfection, we’ve set benchmarks for others to follow and new limits for us to test. This is our mission. We plan to continually push the boundaries of technology and create products that challenge the imagination far into the future.
Table of Contents We wanted to create the world’s most powerful handheld laser - we succeeded and inadvertently set a world record in doing so. We are extremely proud to be included in the Guinness Book of World Records for 2007. This will serve as a testament to our commitment to providing the world with the most sophisticated laser products technology can offer. Designed and developed by some of the world’s best engineers, the Spyder Series stands at the pinnacle of laser technology.
WWW.WICKEDLASERS.COM Nano Series Stronger, Brighter, Clearer, Better, the Nano is the laser for professionals – true professionals. The green Nano produces up to 15mW of power, enabling you to point with precision from across a football field and it comes with a digital microprocessor that allows you to double-click to keep the laser in on mode indefinitely.
WWW.WICKEDLASERS.COM Laser Diagram Using Your Laser At the back of the laser, rotate endcap counter clockwise to open. S3 Krypton Series | 4 Insert two AAA batteries with the negative (-) end first. Press button for normal operation. Double-click the button to enable constant ON mode.
WWW.WICKEDLASERS.COM FDA Compliant Endcap Diagram Using Your FDA Compliant Endcap 1. Interlock Connection Point 2. Switch Contact / Spring 3. Jumper Wire 4. Remote Interlock Housing 5. Battery Cap 6.
WWW.WICKEDLASERS.COM Laser Warning Labels Safety and Maintenance CAUTION - Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. 1. No scheduled maintenance necessary to keep the product in compliance. Simply keep the laser free from dust or other contaminates that could cloud or dirty the laser lens or crystal array and operate within recommended parameters. 2. Avoid direct eye and skin exposure to the laser beam.
WWW.WICKEDLASERS.COM Lens Cleaning Procedure and Troubleshooting Types of Common Lens Problems What you need : Procedure : 1. Dirty Lens - The most common problem with your laser 1. Microfiber Cloth - Please make 1. Wash your hand with soap and water. Make sure to dry them properly. sure the microfiber cloth is specifically designed for cleaning lenses. You can find this at your local camera or glasses store. 2.
WWW.WICKEDLASERS.COM Types of Common Lens Problems Types of Common Lens Problems 4. Moisture - We do not recommend using any laser products in highly humid or foggy conditions. If your laser unit is used in these conditions and/or submerged in water, the beam may appear similar to the above picture. You will not be able to clean this as water has condensed inside the lens and/or crystal set. This condition can be repaired by Wicked Lasers, however, will not be covered in your warranty.
WWW.WICKEDLASERS.COM Limitation of Liability Manufacturer’s Warranty In no event shall Wicked Lasers or any of its subsidiaries or affiliates be liable for any indirect, special, incidental or consequential injury to persons or damage to property caused by the use of any of our products. By purchasing from Wicked Lasers, you hereby indicate that you understand and agree to the following: All Nano Series lasers come with a standard 12 Month Manufacturer’s Warranty.
Manufacturer’s Warranty This warranty does not include defects or damages attributable to misuse, normal surface weathering, or damages caused by accidents or fire or other casualty or force majeure or any other causes or occurrences beyond the manufacturer’s control. To claim your warranty, please send this form or email support@wickedlasers.
1-877-952-7377 Unit 1010, Miramar Tower, 132 Nathan Road, Tsim Sha Tsui Kowloon, Hong Kong www.wickedlasers.com | support@wickedlasers.
