DWD 102 Digi-Wave™ Dual-Bay Docking Station User manual Compatible with Digi-Wave™ Models: DLT 300, DLR 360, DLT 100 2.0, DLR 60 2.
System Overview Thank you for purchasing the DWD 102 Digi-Wave™ Dual-Bay Docking Station. The Digi-Wave™ Dock, when used with second-generation Digi-Wave 2.0 products, can be used to receive audio through a Digi-Wave™ receiver (or transceiver) and send the audio into a sound system, or send audio from a sound system to a transceiver for broadcast. There are many applications for the dock; for more information please visit our website and download the DigiWave Dock Applications Guide.
Connectors and Controls Figure 1: Rear View Bay 2 Bay 1 XLR Line Input Bay 2 RCA Line Inputs Bay 2 XLR RCA Auto/ Auto/ XLR Line Line Manual Manual Line Output Outputs Switch Switch Input Bay 2 Bay 2 Bay 2 Bay 1 Bay 1 Power Supply Connector RCA Line Inputs Bay 1 XLR Line Output Bay 1 RCA Line Outputs Bay 1 A478 Figure 2: Top View Bay 1 Power Indicator LED 3 Bay 2
Setup Instructions: 1. Connect the external devices to the XLR or RCA jacks on the back of the Digi-Wave™ Dock (Figure 1). Both RCA and the single XLR input jacks are all mixed internally - but for proper mixing to occur at the output without any adjustments, the following combinations can be used: One single RCA jack by itself, both RCA jacks, the XLR jack by itself, or both RCA jacks and the XLR jack.
Figure 3: Digi-Wave™ Dock Functions DLT 100 2.0 DLR 60 2.0 / DLR 60 Charges Unit with Dock Power Yes (internal battery) ON Yes - with NiMH AAA batteries in DLR only; if no batteries present dock will power DLR (if battery switch is in NiMH position).
DLT microphone mixing with dock sources The dock’s inputs - two mono RCA jacks (-10dBV) and one XLR jack (+4dBu) - are mixed together in the dock, then sent to the DLT 100 2.0. The DLT 100 2.0 then mixes the dock audio with it’s microphone before transmitting. Depending upon what sources are being mixed, there may be a level mismatch between the dock and the DLT’s microphone level. The DLT 100 2.0 includes line-level adjustment for proper mixing. To adjust the DLT 100 2.
Installing the Support Pads Two sets of supporting pads have been supplied with the dock to support the back of the unit(s) when sitting in the dock; thick (1/8”) and thin (1/16”). Use the table below to choose which pad thickness to use (Figure 5). See the diagram below showing where to affix the pads (Figure 6).
DWD 102 Specifications Dimensions Shipping Weight 8.88” x 4.34” x 2.16" (226 mm x 110 mm x 55 mm) LxWxH 1.4 lbs (0.64 kg) Enclosure Black, heavy duty plastic molded top, with steel base and non-skid rubber feet. White legends on back. DC Power Input 2.5mm ID barrel connector, 24VDC input, 750mA, Center Positive. Power Supply Charging Time Williams Sound TFP 048. Input: 100-240VAC 50/60Hz, 18W. Output: 24VDC, 750mA. DLT 100 2.0: 5 hours nominal (internal LiPo Battery)* DLR 60 2.
Troubleshooting No audio transmitted from docked DLT 100 2.0: 1. Make sure the DLT is seated firmly on the dock’s 30-pin connector. 2. Make sure the dock and DLT are powered ON. 3. Check the source input into the dock - make sure it is connected, powered on and playing/producing audio. 4. Verify that the incoming audio level is sufficient. 5. Make sure the TALK button red ring light is ON on the DLT. 6. Make sure the DLT is set up as a Chairman Master (recommended).
One or more source audio levels too quiet or too loud (not mixing evenly): 1. If the RCA inputs are being used with an XLR source, both RCA inputs must be used to mix evenly with the XLR source. If using a mono RCA source, it must be wyed-out (using a Y-cable or adapter) and sent into both RCA inputs. If just one RCA is used, when mixed with the XLR, it will not mix evenly and will be quieter than the XLR source. 2.
2 Year Warranty Williams Sound products are engineered, designed and manufactured under carefully controlled conditions to provide you with many years of reliable service. Williams Sound warrants the DWD 102 Digi-Wave™ Dual-Bay Docking Station against defects in materials and workmanship for TWO (2) years. During the first 2 years from the purchase date, we will promptly repair or replace the DWD 102.
