WIRELESS MULTI-ROOM SOUNDBAR SPEAKER User’s Guide for Model ISWF776B-1519-01 ISWF776-1519-01-IB - 042616.
Warnings & Precautions FCC Warnings • Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Table of Contents Introduction Features* - 5 Includes* - 5 Overview Top View - 6 Rear View - 6 Speaker Controls - 7 Indicators - 7 Remote - 8 Remote Batteries - 8 Connecting Other Devices Stereo RCA Inputs (Aux In) - 9 Optical Input - 9 Power & Charging Charging The Speaker - 10 Wi-Fi Control App App Download - 11 Initial Setup & Connecting To Wi-Fi - 11 Alternative Wi-Fi Setup - 12 Main Screen/Now Playing - 13 Music Menu - 14 Internet Music Services - 15 My Music - 16 Setting Presets - 17 Device List - 18
Introduction Make your home audio ready with our Wi-Fi speakers and easy to use app. Connect to Pandora, Spotify or other online music services with the touch of a button and play your favorite songs in any room of the house. FEATURES* » Multi-room/multi-speaker play » On-speaker play, volume, and preset controls » Built-in Wi-Fi & Wi-Fi Direct » Wi-Fi range - 98.
Overview TOP VIEW On Speaker Controls REAR VIEW Speaker Inputs ISWF776-1519-01-IB - 042616.
Overview SPEAKER CONTROLS »» Power Press and hold to power the speaker ON or OFF. »» Select Source Press to switch between Wi-Fi, Optical and Aux modes. » Pair Wi-Fi Connect Press to begin searching for Wi-Fi networks while in Wi-Fi mode. »» Play/Pause A short press will pause or play audio. »» Skip Track/Volume Press and hold to skip between tracks.
Overview REMOTE 2 1 4 3 5 1. Power ON/OFF 2. Mute 3. Play/Skip/Volume 4. Source Select: Wi-Fi/Aux/Optical 5. Presets 1-6 ER Y CR2025 OPEN LI TH IU CR M 2 BA 3V 025 TT PUSH Y ER TT BA M 25 IU 20 TH CR 3V LI CR2025 OPEN REMOTE BATTERIES PUSH ISWF776-1519-01-IB - 042616.
Connecting Other Devices STEREO RCA INPUTS (AUX IN) When connecting two products using an RCA audio cable (included), match the colored ports (red/white) to their corresponding plugs. »» Use an RCA to 3.5mm audio cable (included) to connect the RCA Stereo Inputs on the back of the speaker to the headphone jack on a smartphone or other audio source. »» Power on the speaker and press the Source button to select Aux In, indicated by a green light on the speaker.
Power & Charging CHARGING THE SPEAKER The speaker should be fully charged before use. A fully charged battery should last for approximately 4 hours of continuous use at 50% volume. Play time will decrease at louder volumes and increase at lower volumes. It is not recommended to charge the speaker overnight. Connect power plug to Power Input. Connect to standard wall outlet. ISWF776-1519-01-IB - 042616.
Wi-Fi Control App APP DOWNLOAD The iLive Platinum Wi-Fi Control app lets you play music and audio from streaming services like Pandora, Spotify and others. It also controls the speaker’s other functions, like multi-room play, multi-channel play, etc. Download the app for your device by scanning the QR codes below, or searching for the iLive Platinum Wi-Fi Control app in the Apple App Store™ or Google Play Store™.
Wi-Fi Control App ALTERNATIVE WI-FI SETUP If you are having trouble connecting your phone to the speaker or the speaker to your Wi-Fi network (time/percentage runs out), the app will automatically detect the malfunction and provide steps for a different connection method. This connection type involves accessing your phone’s Wi-Fi settings to first connect the phone to the speaker, then the speaker to your wireless router/Wi-Fi network.
Wi-Fi Control App MAIN SCREEN/NOW PLAYING Service 12:00 PM iLive 1 75% ISWF776 Swipe for Music Menu 2 Swipe for Device Menu 3 4 Song Title Artist 00:00 00:00 5 6 7 1. Music Menu 4. Current Playlist 2. Current Speaker/ Device Menu 5. Repeat/Shuffle 3. Add to Favorites 7. Play Controls ISWF776-1519-01-IB - 042616.indd 13 6.
Wi-Fi Control App MUSIC MENU 1 2 3 4 1. SEARCH Search for songs, albums and artists. 2. FAVORITES Open songs, artists, albums, or stations that you have saved. ISWF776-1519-01-IB - 042616.indd 14 3. MY MUSIC Open music that is stored on your phone or tablet. 4. INTERNET MUSIC SERVICES Can be enabled or disabled in Settings.
Wi-Fi Control App INTERNET MUSIC SERVICES The iLive Platinum app supports and can play songs from Pandora, Spotify, iHeartRadio, TuneIn, and Tidal. If you already have accounts with any of these services, the app will prompt you to sign in so that it can access any songs or stations you may already have saved with that service.
Wi-Fi Control App MY MUSIC 1 2 3 4 1. THIS PHONE/TABLET Find music stored on the phone or tablet you are currently using. 3. RECENTLY PLAYED Browse and open any recently played music. 2. MY PLAYLISTS 4. CURRENT SPEAKER & TRACK Open and create playlists in the app Press to return to the Main/Now or link a playlist from another source. Playing screen. ISWF776-1519-01-IB - 042616.
Wi-Fi Control App SETTING PRESETS Preset List 1-6 (internet radio stations shown) You can set up to six presets for fast and easy play from the app or just the speaker. Any station, playlist, or album can be set as a preset*. To set a preset, press the button on the Music screen, select the preset slot of your choice (1-6) and confirm the selection. You can now press the corresponding preset button on the speaker or the app to play that music. *Presets not compatible with Spotify.
Wi-Fi Control App DEVICE LIST 1 2 3 4 1. ADD DEVICE Add more speakers for more play options. 3. AUDIO CHANNEL SELECTOR Set audio channels for the speaker L / R / LR (left/right/stereo). 2. SPEAKER SETTINGS Rename a speaker, set preset stations, and find additional information on a speaker. 4. DEVICE HELP Click for help on setting up additional devices. ISWF776-1519-01-IB - 042616.
Wi-Fi Control App ADDING SPEAKERS/DEVICES The procedure for adding more speakers is almost the same as the initial Wi-Fi setup for button and follow the on screen the first speaker. From the Device screen, press the prompts to connect a new iLive Wi-Fi speaker to your Wi-Fi network. When successfully completed, the new speaker should appear in the Device List, and be ready to use. MULTI-ROOM PLAY Place speakers in any room and use the app to play music from the speaker of your choice.
Troubleshooting PROBLEM Cannot complete Wi-Fi network set up POSSIBLE SOLUTION »» Make sure the speaker has power and is charged. »» Make sure you are connecting to the right network. »» If using a dual band wireless router, be sure to use the 2.4G frequency. »» Be sure to enable Wi-Fi on your mobile device. »» Test your internet connection by loading/reloading a web page. If you cannot load the page, you may need to restart your router. »» Use an alternate connection method (pg.
Company Information CONTACT INFORMATION WARRANTY INFORMATION Website: www.iLiveElectronics.com Email Support: prodinfo@dpiinc.com Email Parts: partsinfo@dpiinc.com Phone Support: 1-888-999-4215 For Warranty Information and the most up-to-date version of this User’s Guide, go to: www.iLiveElectronics.com INTERNATIONAL SUPPORT To download this User’s Guide in English, Spanish, or French, or to get answers to frequently asked questions, visit the support section at: www.iLiveElectronics.
