Spurious Rejection
Analog (12.5 kHz) -65 dB (NTIA Version: -70 dB)
Analog (25.0 kHz) -70 dB (NTIA Version: -85 dB)
Digital (5% BER) -70 dB (NTIA Version: -85 dB)
Unwanted Emissions
Narrow Band -60 dBm
Wide Band -60 dBm
Frequency Stability ± 1.5 PPM
Audio Output
Headset Out 100 mW Maximum into 600 ohms
Normalized Out 1.75 VRMS into 10k Load
External Speaker Out .9 VRMS into 10k Load
Audio Distortion < 2% at Maximum Audio Output
Hum and Noise
Unsquelched <-40 dB
Squelched <-50 dB
Transmitter Specifications
Duty Cycle 25% at Full Power, Continuous at reduced power.
RF Power Output 10 Watt Hi, 1 Watt Lo (3/1 Watt 800 MHz Band Only)
Frequency Stability ± 1.5 PPM
Modulation Limiting:
12.5 kHz Channels ±2.5 kHz
20.0 kHz Channels ±4.0 kHz
25.0 kHz Channels +5.0 kHz
Unwanted Emissions < -70 dBc (-70 dBc Harmonics, -85 dBC Spurious)
Hum and Noise
Narrow Band -42 dB
Wide Band -48 dB
Audio Response
Dual Microphone .25 VMRS into 150 ohm Carbon or Carbon Equivalent
Transmit Distortion < 2%. @ 1 kHz
Sidetone Fidelity 6 dB max variation, 350 Hz to 2500 Hz
Sidetone Output Adjustable 0 to –30 dB below rated output.
