D. Antenna Options
The following antennas are required for use with the P-2000/RT-2000 Transceivers.
Antenna Name Wulfsberg Part
Number
Frequency Band FAA Certification
AT-695 121-0019-000 136-174 MHz TSO
AT-462 121-014378-01 380-520 MHz PMA
AT-806 121-019079-01 806-870 TSO
See Figure 2-1, 2-2,2-3 for envelope drawings of antennas.
E. RT-2000 Mounting Tray (Wulfsberg P/N 300-XXXXXX-01)
See Figure 2 –4 for envelope drawing of RT-2000 Mounting Tray.
F. Required Accessories
Part Type Part Description Wulfsberg Part Number
Connector DB-25 Connector 030-02703-0000
Connector component DB-25 Backshell 129-214803-25
Connector component DB-25 Slide Locks 129-141470-25
Connector DB-15 Connector 129-217927-01
Connector component DB-15 Backshell 129-241803-15
Connector component DB-15 Slide Locks 129-141470-15
RF Connector Straight TNC for RG-193 Coax Cable 129-041810-01
RF Connector Right angleTNC for RG-193 Coax Cable 129-041811-01
Cable RT-2000 KVL Data Cable 300-349082-01
Software XTS-3000 PC Programming Software ***Available from Motorola
Software XTS-5000 PC Programming Software ***Available from Motorola
***XTS-3000 PC Programming Software (RVN4184) is required for transceiver options 1
through 4. Options 5 and 6 require XTS-5000 PC Programming Software(RVN4186). These
Motorola part numbers are subject to change without notice.
Motorola Software must be obtained by the operator directly from Motorola Customer Service
Department via the following telephone numbers:
U.S. and Canadian Customers 1-800-422-4210
Federal Government Customers 1-800-826-1931
Outside U.S. Customer 1-847-538-8023
