4. Technical Characteristics
A. P-2000 Panel Mount Transceiver
CHARACTERISTICS DESCRIPTION
Certification
FAA In Process (STC Helicopter and Fixed Wing Aircraft)
Software DO-170B Level D
Environmental DO-160D
[(B4/F1)X]BAB[S/U]EXXXXXZZAZZ[J/F]M[XXC3]XXA
FCC FRW-2000-(VHF,UHF-1,UHF-2, 800)
Industry Canada TBD
Emission Designator
156 – 158 MHz Part 80.379, 87.187(l), 16K0F3E
136 – 174 MHz Part 90.210, 16K0F3E, 11K0F3E, 8K10F1E, 8K0F1D
403 – 520 MHz Part 90.210, 16K0F3E, 11K0F3E
806 – 870 MHz Part 90, 16K0F3E, 11K0F3E, 8K10F1E, 8K0F1D
Altitude 51,000 feet ASL (15,545 meters)
Temperature Range
Operation
-30°C to 60°C (-22°F to +140°F)
Storage
-55°C to 85°C (-67°F to +185°F)
Cooling Internal Electric Fan
Weight
P-2000 (Single Transceiver) 3.10 lbs. Max.
P-2000 (Dual Transceiver) 3.70 lbs. Max.
Mounting Dzus
Height 3.0 Inches max.
Width 5.75 inches max.
Depth 6.40 Inches max. (Not Including Connectors)
Input Power Requirements
Normal Voltage Range 22.0 to 30.2 VDC
Abnormal Voltage Range 20.5 to 32.2 VDC
Emergency Operation 18.0 VDC
P-2000 (Single Transceiver)
Receive 0.5 Amp Nominal. .75 Amp Max
Transmit 2.5 Amp Nominal. 3.0 Amp Max.
P-2000 (Dual Transceiver)
Receive 0.5 Amp nominal. 1.0 Amp Max
Transmit 3.0 Amp nominal. 4.0 Amp Max.
P-2000 Panel Lighting 5 VDC, 5 Vrms and 28 VDC (Voltage Sense Only)
Faceplate Colors Black or Grey
Channel Memory 240/255/510 Depending on options
Frequency Band P-2000/RT-2000 Any combination of one or two bands listed below
136-174 MHz, 136-174 MHz (NTIA Compliant)
403-470 MHz, 380-470 MHz
450-520 MHz
