B. C-2000 Control Display Unit
CHARACTERISTICS DESCRIPTION
Certification
FAA In Process (PMA/STC Helicopter and Fixed Wing Aircraft)
Software DO-170B Level D
Environmental DO-160D
[(B4/F1)X]BAB[S/U]EXXXXXZZAZZ[J/F]M[XXC3]XXA
FCC Part 15
Industry Canada Pending
Altitude 51,000 feet ASL (15,545 meters)
Temperature Range
Operation
-30°C to 60°C (-22°F to +140°F)
Storage
-55°C to 85°C (-67°F to +185°F)
Cooling Internal Electric Fan
Weight 2.00 lbs. Max.
Mounting Dzus
Overall Dimensions
Height 3.0 Inches max.
Width 5.75 inches max.
Depth 6.40 inches max. (without Connectors)
Input Power Requirements
Normal Voltage Range 22.0 to 30.2 VDC
Abnormal Voltage Range 20.5 to 32.2 VDC
Emergency Operation 18.0 VDC
Input Current 0.5 Amp nominal. 1.0 Amp Max
Panel Lighting 5 VDC, 5 Vrms and 28 VDC (Voltage Sense Only)
Faceplate Colors Black or Grey
Display Options LCD Color or LCD Color with NVG compatibility
Channel Memory 240/255/510 Depending on options
Data Bus CAN Serial with Wulfsberg Proprietary Protocol
C. RT-2000 Remote Mount Transceiver
CHARACTERISTICS DESCRIPTION
Certification
FAA In Process (PMA/STC Helicopter and Fixed Wing Aircraft)
Software DO-170B Level D
Environmental DO-160D
[(B4/F1)X]BAB[S/U]EXXXXXZZAZZ[J/F]M[XXC3]XXA
FCC Pending FRW-2000-(VHF,UHF-1,UHF-2, 800)
Industry Canada Pending
Emission Designator
156 – 158 MHz Part 80.379, 87.187(l), 16K0F3E
136 – 174 MHz Part 90.210, 16K0F3E, 11K0F3E, 8K10F1E, 8K0F1D
403 – 520 MHz Part 90.210, 16K0F3E, 11K0F3E
806 – 870 MHz Part 90, 16K0F3E, 11K0F3E, 8K10F1E, 8K0F1D
Altitude 51,000 feet ASL (15,545 meters)
