User's Manual

P-2000/C-2000/RT-2000
INSTALLATION MANUAL
Publication No. 150-049106 Page 9 of 41
Rev. A P-2000 Installation Manual
Oct 2003
Temperature Range
Operation
-30°C to 60°C (-22°F to +140°F)
Storage
-55°C to 85°C (-67°F to +185°F)
Cooling Free air circulation
Weight
RT-2000 (Single Transceiver) 2.50 lbs. Max.
RT-2000 (Dual Transceiver) 3.50 lbs. Max.
Mounting Mounting Tray
Overall Dimensions
Height 3.0 inches max.
Width 5.75 inches max.
Length 7.49 inches max (without Connectors)
Input Power Requirements
Normal Voltage Range 22.0 to 30.2 VDC
Abnormal Voltage Range 20.5 to 32.2 VDC
Emergency Operation 18.0 VDC
RT-2000 (Single Transceiver)
Receive 0.5 Amp nominal. .75 Amp Max
Transmit 2.5 Amp nominal. 3.0 Amp Max.
RT-2000 (Dual Transceiver)
Receive 0.5 Amp nominal. .75 Amp Max
Transmit 3.0 Amp nominal. 4.0 Amp Max.
Frequency Band P-2000/RT-2000 Any combination of one or bands listed below
136-174 MHz, 136-174 MHz (NTIA Compliant)
403-470 MHz, 380-470 MHz
450-520 MHz
806-870 MHz
Data Bus CAN Serial with Wulfsberg Proprietary Protocol
Encryption Options DES/DES-XL/DES-OFB/AES/DVP/DVI
OTAR Options MDC1200 OTAR, P25 OTAR
Trunking Options Smartzone, P25
Receiver Specifications
Modes FM, P-25, P-25 Trunking, Motorola 3600 Baud Trunking
Sensitivity
Analog (12 dB SINAD) Better than .4 uV (-115 dBm)
Digital (5% BER) Better than .4 uV (-115 dBm)
Quieting
Analog (20 dB SINAD) .6 uV (-111.5 dBm)
Digital Not Applicable
Selectivity
Analog (12.5 kHz) -65 dB (NTIA Version: -70 dB)
Analog (25.0 kHz) -70 dB (NTIA Version: -80 dB)
Intermod Rejection
Analog (12.5) -70 dB
Analog (25.0) -70 dB
