Data Sheet

Properties Test conditions Value Unit
Pitch P per Row 2.54 mm
Quality Class 25 Mating cycles
Gender Female
Kind Properties:
Insulator Material PA6T
Insulator Flammability Rating UL94 V-0
Insulator Color Red
Contact Material Phosphor Bronze
Contact Plating Mat Tin over Nickel
Contact Type Stamped
Material Properties:
Properties Value Unit
Operating Temperature -40 up to +105 °C
Compliance Lead free / RoHS
General Information:
Properties Test conditions Value Unit Tol.
Rated Current I
R
per Pin (PCB) 1.5 A
Working Voltage 100 V (AC)
Withstanding Voltage 1 min 500 V (AC)
Contact Resistance R 10 mΩ max.
Insulation Resistance R
ISO
1000 MΩ min.
Electrical Properties:
cULus Approval E323964
Certification:
Packaging Tape and Reel
Packaging Properties:
Würth Elektronik eiSos GmbH & Co. KG
EMC & Inductive Solutions
Max-Eyth-Str. 1
74638 Waldenburg
Germany
Tel. [phone] - 0
www.we-online.com
[e-mail]
CREATED CHECKED GENERAL TOLERANCE PROJECTION
METHOD
DaSc GM DIN ISO 2768-1m
DESCRIPTION
WR-MM Female SMT Connector
with Polarization
ORDER CODE
690367281076
REVISION STATUS DATE (YYYY-MM-DD) BUSINESS UNIT PAGE
001.003 Valid 2018-09-12 eiCan 2/5
