The MCU on the receiver side is required for the proper configuration of the RX IC. Without the configuration the RX is not sending
the needed parameters during the negotiation/calibration phase to enable the medium power transfer mode. The I2C interface is
used to set the necessary parameters such as the LDO output voltage, the current limit, FOD and QFOD settings.
The receiver system of this design kit uses a modular approach: The Load Module is designed as stackable shield on top of the
Receiver Module. This allows easy replacement of the demonstrative LED matrix load and receiver side MCU. The user may design
a custom load/MCU shield or connect to the RX Module pin headers by jumper cables.
Interoperability between transmitter and receiver is achieved by complying with the WPC Qi standard. The Transmitter Module can
supply power to any Qi compliant receiver and equally the Receiver Module can receive power from any Qi compliant transmitter.
Also, both modules are backwards compatible with a low power (baseline power profile) counterpart.
2.2 Key components
The purpose of the EVK is the evaluation of the key components used to realize the wireless power system. Table 1 gives an
overview of the different ICs and coils. For more detailed information about these devices please follow the given hyperlinks to the
individual web pages and datasheets.
Manufacturer
Product
Part Number
Used in
Rohm Semiconductor
Wireless Power Transmitter IC
BD57020MWV
TX Module
Rohm Semiconductor
Step-Down Switching Regulator
BD9E151NUX
TX Module
Rohm Semiconductor
Wireless Power Receiver IC
BD57015GWL
RX Module
Rohm Semiconductor (Lapis)
Microcontroller
ML610Q772-B03
TX Module
Rohm Semiconductor (Lapis)
Microcontroller
ML610Q112
LED Module
Rohm Semiconductor
LED driver 8ch
BD6142AMUV
LED Module
Würth Elektronik eiSos
Transmitter Coil
760 308 110
TX Module
Würth Elektronik eiSos
Receiver Coil
760 308 102 207
RX Module
Table 1: Key components used in the design kit
2.3 Schematic, Gerber Files and Bill of Materials
Please visit www.rohm.com/web/eu/wirelesspowerkit for downloading the latest production data consisting of the schematics,
assembly data, Gerber files and Bill of Materials (BOMs) for all three modules of this design kit.
