Data Sheet

1.1
1.0
REV
2014-08-14
2014-05-14
DATE
SSt
SSt
BY
PSL
PSL
CHECKED
Würth Elektronik eiSos GmbH & Co. KG
EMC & Inductive Solutions
Max-Eyth-Str. 1
74638 Waldenburg
Germany
Tel. [phone] - 0
www.we-online.com
[e-mail]
DESCRIPTION
WCAP-FTX2 Foil Capacitors
Order.- No.
890324024002CS
SIZE
A4
Size: Pitch 12.5 mm - PL 4
Component Marking:
Print
1
st
Line right
2
nd
Line right
3
rd
Line right
1st Line left
Bottom line
Top Cover Marking P < 15
Top Cover Marking P ≥ 15
Description
Matchcode: FTX2
Rated Voltage: 275 V~
Climate Category: 40/105/56/B
Capacitance & Tolerance Code: 224K (Basis pF)
Certificates: ENEC, cULUS, CQC & Internal Marking
Date Code: YWW
Date Code & Capacitance & Tolerance Code
D2 Approvals:
Properties
ENEC10 by VDE
cULus
CQC
Standard
IEC 60384 - 14
UL 60384 - 14 / CAN/CSA - E60384 - 14
IEC 60384 - 14
File
40038405
E345659
13001104051
D3 Mechanical Properties:
Properties
Termination Robustness
Test Conditions
IEC 600668 - 2 - 21 Pull Test
Bend Test
Lead diameter [mm]
0.5 to ≤ 0.8
0.9 to ≤ 1.25
0.5 to ≤ 0.8
0.9 to ≤ 1.25
Force [N]
10
20
5
10
condition
min. 10 sec.
min. 10 sec.
min. 2 cycles
min. 2 cycles
D4 Environmental Tests:
Properties
Active Flammability
Passive Flammability
Vibration
Damp Heat
Temperature Cycles
Charge/ Discharge Test
Surge Test
Standard
IEC 60384-14
IEC 60384-14
IEC 60068 - 2 - 6
IEC 60068 - 2 - 78
IEC 60068 - 2 - 14
IEC 60384 - 14
IEC 60384 - 14
max. 24 surge pulses @ 2.5 kV (one pulse every 5 seconds)
in combination with IEC 60381 - 1 & IEC 60695 - 11 - 5
all 3 directions, 2 hours each @ 10 - 55 - 10 Hz, amplitude 0.75 mm or 10 g
40°C, 95% RH, 56 days
5 cycles, upper and lower temperature 30 min. each, 30 sec. transfer time
√2 x U
R
@ 100 V/µs
2.5 kV Surge impulses
