d CLOUD POS PAYMENT DEVICE XCL_E200NP SERIES INSTALLATION GUIDE xCL_E200NP series: - xCL_E200NP-UN5 xCL_E200NP-UNN xCL_E200NP-NN5 xCL_E200NP-NNN xCL_E200NP-EN5 xCL_E200NP-ENN
1. PACKAGE CONTENT xCL_E200NP Power adaptor USB cable 2. DEVICE OVERVIEW Take a view on your xCL_E200NP to find these Key Buttons & Interface Ports in Figure 1: Front Side (L) Figure 1 1. - Speaker 2. - Touch Display 3. - Magnetic Strip Reader slot 4. - Smart Card Reader slot 5. - Audio Jack 6. - Mini USB port 7. - Power Button 8. - Charging pins 9. - Camera 10.
■ POS spec Input: 5V DC, 2A ■ Power Adapter spec: Input: 100~240 Vac Output: 5V DC, 2A This symbol is intended to alert the user before starting using the POS. ( Caution: Use only the AC adapter approved and provided by XAC Automation Corporation for use with this device. Use of any other AC adapter may cause a risk of fire or explosion) o o Operating Temperature: 0 C to 40 C 2.
Figure 3 4. USING THE IC CARD READER The IC card reader slot is on the bottom of the device (Figure 4). Insert an IC card into the slot with the chip side facing the same direction as the touch panel (Figure 5). Figure 4 Figure 5 5. USING THE VIRTUAL KEY PAD After inserting the chip card, Press the numeric key as below Figure 6 to enter the desirable numbers. Press Cancel(X) key to terminate any current function and press the Enter(O) key to confirm a value or an option. Figure 6 7.
Figure 7 8. REMOVE THE BATTERY STEP 1: Use the screw driver to remove 3 screws on the bottom cover as Figure 8. STEP 2: After removing the bottom cover, pull up the battery connector as below Figure 9 to change a new battery. Figure 8 Figure 9 Bottom Cover Removal Warning When removing the bottom cover and screws for the purposes of changing battery, remember to put back the cover and screws before power on the POS. CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
Do not heat above 60 oC 3. 8. INSERT SIM & SAM CARD After removing the battery, the user can find SIM (left) & SAM (right) slots at the bottom side of device. Please insert the card correctly as the icon shown on the cover: Figure 10 FEDERAL COMMUNICATION COMMISSION INTERFERENCE STATEMENT This device complies with Part 15 of the FCC Rules.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Operations in the 5.15-5.
