3. Antenna
Two types of antennas are support by this module:
1. The PCB trace antenna defined in the original Murata LBEE5HY1MW documentation
2. An external dipole antenna as described in this section.
3.1 Antenna Characteristics
Xaptum, Inc.
541 N Fairbanks, Suite 2200 2
Chicago, IL 60611
BLE
2402-2480MHz
N/A
✓
W52
11a/n/ac - (V)HT20
5180-5240MHz
Active
✓
✓
11n/ac - (V)HT40
5190-5230MHz
Active
✓
✓
11ac - VHT80
5210MHz
Active
✓
W53
11a/n/ac - (V)HT20
5260-5320MHz
Passive
✓
11n/ac - (V)HT40
5270-5310MHz
Passive
✓
11ac - VHT80
5290MHz
Passive
✓
W56
11a/n/ac - (V)HT20
5500-5720MHz
Passive
✓
11n/ac - (V)HT40
5510-5710MHz
Passive
✓
11ac - VHT80
5530-5690MHz
Passive
✓
W58
11a/n/ac - (V)HT20
5745-5825MHz
Active
✓
✓
11n/ac - (V)HT40
5755-5795MHz
Active
✓
✓
11ac - VHT80
5775MHz
Active
✓
Antenna
Antenna Type
External dipole
Max Gain 2.4 GHz
5 GHz
3.0 dBi
5.0 dBi
