XEROX WIDE FORMAT AccXES Firmware 10.
Table of Contents 1 1.1 Introduction FEATURE KEYS: 1.1.1 2 2.1 2.2 2.3 2.4 2.5 3 4 5 5.1 5.2 6 6.1 6.2 6.3 6.4 7 7.1 Feature Key Descriptions Release Deliverables Xerox 8825, 8830 Print Systems Xerox 8850, 510dp Print Systems Xerox Print System 721p Xerox Print System X2 TECH Xerox 6030/6050 Wide Format Solution Recommended Configurations Release Installation New Features of 10.0 b 140 Support for 6030/6050 printer Force PP = 0 New Features of 9.
7.6.1 7.6.2 7.6.3 7.6.4 7.6.5 7.6.6 7.6.7 7.6.8 7.6.9 7.6.10 7.6.11 7.6.12 7.6.13 7.6.14 7.6.15 7.6.16 7.6.17 Printer Queue – Main WebPMT Screen Backlit-Film media type Netscape 6.1 users only Netscape 7.
1 Introduction The AccXES Controller Firmware Release 10.0 b 140 provides multinational software for the Xerox Wide Format Print Systems 8825, 8830, 8850, 510dp, 721p, the Xerox Wide Format Print System X2 TECH, the Xerox 6030/6050 Wide Format Solution, and for their Xerox Wide Format scanners. The languages supported are English, Deutsch, Espanol, Francais, Italiano, and Portugues. This document presents the following information about the AccXES Controller Release 10.0 build 140.
• PostScript • Xerox Wide Format Scanner Features: Scan To Net (to create an electronic file from a scanned image) Scan to Print (to scan, create a preview, and send to the scanned image to the printer when Scan-to-Net is present) Color Enablement – AccXES (Allows color scanning when scan to net license is preset) Speed Enhancement Turbo II – AccXES (4 ips for 36” wide) Speed Enhancement Turbo III – AccXES (HFT Controller only: 7.
2 Release Deliverables 2.1 Xerox 8825, 8830 Print Systems The following executables are provided for the Xerox Wide Format Print System 8825, 8830 and support the Xerox Wide Format Scan System scanner. NOTE: You must load version 9.0 before loading this Firmware NOTE: If your release is below 6.0, you must upgrade to 5.99 then to 9.0 before loading this Firmware. HFT Controller – HFT_8830_10_0b140.disk.bin (file size = 7,570,724 bytes) CNG Controller – CNG_8830_10_0b140.disk.
2.3 Xerox Print System 721p The following executables are provided for the Xerox Wide Format Print System 721p and support the Xerox Wide Format Scan System scanner. HFT Controller – HFT_721p_10_0b140.disk.bin (file size = 7,526,470 bytes) 2.4 Xerox Print System X2 TECH The following executables are provided for the Xerox Wide Format Print System X2 TECH and support the Xerox Wide Format scanner. KLF Controller – KLF_X2_10_0b140.disk.bin (file size = 16,611,333 bytes) HFT Controller – HFT_X2_10_0b140.disk.
3 Recommended Configurations Table 1: Minimum (Min.) and Recommended (Rec.) RAM Configurations (MB) UP8 controller is no longer supported. N5T, CNG Controllers EV4 Controller KLF Controllers HFT Controller Min. Rec. Min. Rec. Min. Rec. Min. Rec.
4 Release Installation NOTES: Feature keys from before version 9.0 B180 are no longer useable with version 10.0 firmware. New keys must be acquired from the Xerox website to use your system. Downgrading below 9.0 B 180 will also require you to re-download your feature keys. The AccXES Revision MUST be 9.0 or higher to upgrade to 10.0. If your current version is lower than 9.0, you must install 9.0 or higher before upgrading to 10.0.
5 New Features of 10.0 b 140 5.1 Support for 6030/6050 printer Via a new WebPMT page “Configure Remote Printer” the AccXES HFT controller can now become a Print Server for a 6030/6050 Wide Format printer via an Ethernet connection. SNMP must be enabled on the 6030/6050 printer. If the Printer is on a different subnet than the AccXES controller then static routing must be enabled on the 6030/6050 printer.
6 New Features of 9.5 b 111 6.1 Single Page Job This feature, when enabled, will concatenate adjacent pages in a job that are the same width to produce a long strip of paper for the job. If the Single Page Job feature is set to a specific roll size, then all pages of the job will be forced to that width guaranteeing that they are all concatenated. If the Single Page Job feature is set to Auto, only those adjacent pages that print on the same roll will be concatenated.
With 9.5 AccXES controller firmware and 3.2.5 Xerox Wide Format Scanner firmware or higher, it is now possible to move a feature key from one scanner to another.
7 Release Notes The following information supplements the 10.0 customer user guides. 7.1 Controller 7.1.1 HFT and KLF Controller on the Xerox Wide Format Print System X2 TECH Rebooting procedure When the Controller is rebooted, the X2 TECH printer must also be rebooted. This is due to communication along the SCSI chain. If the controller is in the middle of a SCSI command at the time it is rebooted, the printer no longer communicates.
7.2 Xerox Wide Format 721P Printer only 7.2.1 Job Cancel from the 721p Control Panel The current job can be cancelled using the 721 Control Panel. Please note that if you wish to cancel the next job in the queue, you must put the printer back on-line and then take it off-line again. The Job Cancel feature only cancels one job at a time, the current job. 7.3 Xerox 6030/6050 Wide Format Solution 7.3.1 Long Plotting Long plot limits are dependent on the amount of memory in the 6030/6050.
7.4.3 Upgrade Test Print After upgrading to the latest scanner firmware, check the Scanner Configuration section at the bottom of the Configuration Test Print. If “None” shows for the values of Type, Product, Firmware, and Vendor, then print out another test print to view the correct values. 7.4.4 Scan-to-Print and Margins When performing a scan-to-print operation the scanned image is printed using the current printer processing defaults including margins.
7.5.1 Manual feed media source will be ignored when used with the AccXES Client Tools’ page composition feature. Go to AccXES Client Tools > Job Option tab > Composition tab > Select Overlay Images > Media Source drop down menu. Although “Manual Feed” is listed as a choice of media source for page composition jobs, the print job will be treated as if AUTO media source was selected.
there can be scan errors; when there are fewer jobs in the queue, the jobs can then be resubmitted or scanned. Additionally, completed jobs will be removed from the queue display immediately to make room for the newly submitted print jobs. To avoid these issues, keep the number of active print jobs to under the 128 limit.
What to do: • Set Mismatch Mode to Substitute • Request a Media Size of ARCH E via WebPMT, ACT, or the Driver • Request a Media Size 36" Roll via WebPMT, ACT, or the Driver 7.6.7 Pen Palettes For Internet Explorer version 5.00.3105.0106, when you try to save a pen palette it opens instead; you might have to manually copy and paste the pen palette information into a file. (To locate your Internet Explorer version number, select Help > About in your browser toolbar.)" 7.6.
7.6.12 Default PostScript Page Size If a PostScript job does not specify a page size (either by using a compatibility operator such as “letter”, or “a4”, or by using the setpagedevice operator /PageSize parameter), the page size used is the one specified by the Default PostScript Page Size parameter available via the printer user interface, or via the Web PMT. 7.6.13 String value of “0” in Text Fields A string value of “0” cannot be assigned to text fields.
pattern is opened in Paint, any attempt to save the file will result in Paint crashing and no file saved. 7.6.16 Printer Password The printer password appears in the location (address) bar of the web browser. When a user types in a password in the text box, an asterisk is displayed for each digit entered. However, when the “UPDATE PRINTER” or “Submit” button is pressed, the password value is displayed on the web page in the location bar of the browser.
8 Customer Issues Resolved 8.1 The following Customer issues were resolved in 10.0 b 140 Issue Description Problem Resolution Lines are missing from Microsoft Project file when printed via Windows System Driver Lines were defined as filled polygons, but AccXES rendered them with the coordinate system falling on the corners of the pixels and so there was no area inside the polygon to fill. AccXES now defaults to coordinates system on the pixels themselves which causes a single pixel line to be “filled”.
9 Appendix 9.1 HFT Controller Installation for Xerox Wide Format Print System 8830 IMPORTANT NOTE: The controller will only accept the installation when there are no active jobs being processed. 9.1.1 AccXES Client Tools Download the file named “HFT_8830_10_0b140.disk.bin”. A status sheet will be printed and indicate that the download was successful. NOTE: Make sure that the connection to the scanner is enabled. This is done on the Web PMT, by going to Printer Defaults > Printer Setup.
9.2.1 AccXES Client Tools Download the file named “HFT_8850_510dp_10_0b140.disk.bin”. A status sheet will be printed and indicate that the download was successful. NOTE: Make sure that the connection to the scanner is enabled. This is done on the Web PMT, by going to Printer Defaults > Printer Setup. Select the “DDS Enabled” box. Reboot the controller. 9.2.2 Web PMT Select PRINTER DEFAULTS > UTILITIES > Upload File. Use the Browse button to select the “HFT_8850_510dp_10_0b140.disk.bin” file.
9.3.3 Unix Download the software using LPR with the following command line: lpr –P printername HFT_721p _10_0b140.disk.bin A status sheet will be printed and indicate that the download was successful. NOTE: Make sure that the connection to the scanner is enabled. This is done on the Web PMT, by going to Printer Defaults > Printer Setup. Select the “DDS Enabled” box. Reboot the controller. 9.
IMPORTANT NOTE: The 6030/6050 requires an 80 GB hard drive. The controller will only accept the installation when there are no active jobs being processed. 9.5.1 AccXES Client Tools Download the file named “HFT_6030_10_0b140.disk.bin”. A status sheet will be printed and indicate that the download was successful. NOTE: Make sure that the connection to the scanner is enabled. This is done on the Web PMT, by going to Printer Defaults > Printer Setup. Select the “DDS Enabled” box. Reboot the controller. 9.5.
