All XFX graphics cards listed are Vista ready.

* See XFXforce.com for the complete model number and package contents. All XFX graphics cards include a Serial Number

Door Hanger or Card for convenient reference. Game bundles may be included with certain models/packing during promotional periods.

** Optimal memory speed. Actual speed may vary. The HD 5970 Black Edition reference GPU and memory clock are set at 725 MHz and 4 GHz respectively.

Its overclock performance will depend on the graphics card, system and environmental conditions.

*** Specications subject to change without notice. See XFXforce.com for the latest information.

www.XFXforce.com

Engine

Memory

Model Number

Chipset

Version Clk(MHz) Bus Type Type Size Speed

••

Stream

Cooling HDMI Outputs Profile Features CrossfireX

HD-597X-ENF(*) HD 5970

Black

850 PCI-E 2.1 DDR5 4GB 4.8GHz 3200 Fansink

∆

Double X, S, D11,EF 3

HD-597A-CNB(*) HD 5970

Black

up to 1GHz PCI-E 2.1 DDR5 2GB up to 6Ghz 3200 Fansink

∆

♦,

♠

Double X, S, D11,EF 3

HD-597A-CNF(*) HD 5970

Standard

725 PCI-E 2.1 DDR5 2GB 4Ghz 3200 Fansink

∆

♦,

♠

Double X, S, D11,EF 3

HD-587X-ZNB(*) HD 5870

Black

900 PCI-E 2.1 DDR5 1GB 5GHz 1600 Fansink

Yes

♦,▲,♠

Double X, S, D11,EF 3

HD-587X-ZND(*) HD 5870

XXX

875 PCI-E 2.1 DDR5 1GB 5GHz 1600 Fansink

Yes

♦,▲,♠

Double X, S, D11,EF 3

HD-587X-ZNE(*) HD 5870

865 PCI-E 2.1 DDR5 1GB 5GHz 1600 Fansink

Yes

♦,▲,♠

Double X, S, D11,EF 3

HD-587X-ZNF(*) HD 5870

Standard

850 PCI-E 2.1 DDR5 1GB 4.8GHz 1600 Fansink

Yes

♦,▲,♠

Double X, S, D11,EF 3

HD-585A-ZNB(*) HD 5850

Black

765 PCI-E 2.1 DDR5 1GB 4.5GHz 1440 Fansink

Yes

♦,▲,♠

Double X, S, D11,EF 3

HD-585A-ZND(*) HD 5850

XXX

755 PCI-E 2.1 DDR5 1GB 4.5GHz 1440 Fansink

Yes

♦,▲,♠

Double X, S, D11,EF 3

HD-585A-ZNF(*) HD 5850

Standard

725 PCI-E 2.1 DDR5 1GB 4GHz 1440 Fansink

Yes

♦,▲,♠

Double X, S, D11,EF 3

HD-585X-ZAB(*) HD 5850

Black

765 PCI-E 2.1 DDR5 1GB 4.5GHz 1440 Fansink

Yes

♦,▲,♠

Double X, S, D11,EF 3

HD-585X-ZAD(*) HD 5850

XXX

755 PCI-E 2.1 DDR5 1GB 4.5GHz 1440 Fansink

Yes

♦,▲,♠

Double X, S, D11,EF 3

HD-585X-ZAF(*) HD 5850

Standard

725 PCI-E 2.1 DDR5 1GB 4GHz 1440 Fansink

Yes

♦,▲,♠

Double X, S, D11,EF 3

HD-583X-ZNF(*) HD 5830

Standard

800 PCI-E 2.1 DDR5 1GB 4GHz 1120 Fansink

Yes

♦,▲,♠

Double X, S, D11,EF 3

HD-583X-ZAD(*) HD 5830

XXX

840 PCI-E 2.1 DDR5 1GB 4.5GHz 1120 Fansink

Yes

♦,▲,♠

Double X, S, D11,EF 3

HD-583X-ZAF(*) HD 5830

Standard

800 PCI-E 2.1 DDR5 1GB 4GHz 1120 Fansink

Yes

♦,▲,♠

Double X, S, D11,EF 3

HD-577A-ZND(*) HD 5770

XXX

875 PCI-E 2.1 DDR5 1GB 5.2GHz 800 Fansink

Yes

♦,▲,♠

Double X, S, D11,EF 2

HD-577A-ZNE(*) HD 5770

865 PCI-E 2.1 DDR5 1GB 5GHz 800 Fansink

Yes

♦,▲,♠

Double X, S, D11,EF 2

HD-577A-ZNF(*) HD 5770

Standard

850 PCI-E 2.1 DDR5 1GB 4.8GHz 800 Fansink

Yes

♦,▲,♠

Double X, S, D11,EF 2

HD-577A-ZHF(*) HD 5770

Standard

850 PCI-E 2.1 DDR5 1GB 4.8GHz 800 Fansink

Yes

♦,▲,♠

Double X, S, D11,EF 2

HD-577X-Z5F(*) HD 5770

Standard

850 PCI-E 2.1 DDR5 1GB 4.8GHz 800 Fansink

∆

Standard X, S, D11,EF 2

HD-577X-ZMD(*) HD 5770

XXX

865 PCI-E 2.1 DDR5 1GB 5.1GHz 800 Fansink

∆

♦,

Standard X, S, D11,EF 2

HD-577X-ZMF(*) HD 5770

Standard

850 PCI-E 2.1 DDR5 1GB 4.8GHz 800 Fansink

∆

♦,

Standard X, S, D11,EF 2

HD-577X-ZNE(*) HD 5770

800 PCI-E 2.1 DDR5 1GB 5.1GHz 800 Fansink

Yes

♦,▲,♠

Double X, S, D11,EF 2

HD-577X-ZNF(*) HD 5770

Standard

800 PCI-E 2.1 DDR5 1GB 4.8GHz 800 Fansink

Yes

♦,▲,♠

Double X, S, D11,EF 2

HD-575X-ZND(*) HD 5750

XXX

740 PCI-E 2.1 DDR5 1GB 4.8GHz 720 Fansink

Yes

♦,▲,♠

Double X, S, D11,EF 2

HD-575X-ZNF(*) HD 5750

Standard

700 PCI-E 2.1 DDR5 1GB 4.6GHz 720 Fansink

Yes

♦,▲,♠

Double X, S, D11,EF 2

HD-575X-YHF(*) HD 5750

Standard

700 PCI-E 2.1 DDR5 512MB 4.6GHz 720 Fansink

Yes

♦,▲,♠

Double X, S, D11,EF 2

HD-567X-ZNF(*) HD 5670

Standard

775 PCI-E 2.1 DDR5 1GB 4GHz 400 Fansink

Yes

♦,▲,♠

Double X, S, D11,EF 2

HD-567X-YNF(*) HD 5670

Standard

775 PCI-E 2.1 DDR5 512MB 4GHz 400 Fansink

Yes

■,▲,♠

Standard X, S, D11,EF 2

HD-557X-YNF(*) HD 5570

Standard

650 PCI-E 2.1 DDR3 512MB 1.6GHz 400 Fansink

Yes

■,▲,♠

Low S, D11, EF --

HD-557X-ZHF(*) HD 5570

Standard

650 PCI-E 2.1 DDR2 1GB 1GHz 400 Fansink

Yes

■,▲,○

Standard S, D11 --

HD-557X-ZNF(*) HD 5570

Standard

650 PCI-E 2.1 DDR3 1GB 1.6GHz 400 Fansink

Yes

■,▲,♠

Low S, D11, EF --

HD-555X-ZAF(*) HD 5550

Standard

550 PCI-E 2.1 DDR5 1GB 4GHz 320 Fansink

Yes

■,▲,♠

Standard S, D11, EF --

HD-555X-YHF(*) HD 5550

Standard

550 PCI-E 2.1 DDR5 512MB 4GHz 320 Fansink

Yes

■,▲,♠

Standard S, D11, EF --

HD-555X-ZNF(*) HD 5550

Standard

550 PCI-E 2.1 DDR2 1GB 1GHz 320 Fansink

Yes

■,○,▲

Standard S, D11, EF --

HD-555X-YNF(*) HD 5550

Standard

550 PCI-E 2.1 DDR3 1GB 1.6GHz 320 Fansink

Yes

■,▲,♠

Standard S, D11, EF --

HD-545X-ZNF(*) HD 5450

Standard

650 PCI-E 2.1 DDR2 1GB 1GHz 80 Fansink

Yes

■,○,▲

Low S, D11 --

HD-545X-ZHF(*) HD 5450

Standard

650 PCI-E 2.1 sDDR3 1GB 1.6GHz 80 Fansink

Yes

■,○,▲

Low S, D11 --

HD-545X-YNH(*) HD 5450

Standard

650 PCI-E 2.1 DDR2 512MB 1GHz 80 Heatsink

Yes

■,○,▲

Low S, D11 --

HD-545X-ZAF(*) HD 5450

Standard

650 PCI-E 2.1 sDDR3 1GB 1.6GHz 80 Fansink

Yes

■,▲,♠

Low S, D11, EF --

HD-487A-ZWF(*) HD 4870

Standard

750 PCI-E 2.0 DDR5 1GB 3.6Ghz 800 Fansink

Yes

♦

Double X, S, DX1 3

HD-485X-ZNF(*) HD 4850

Standard

625 PCI-E 2.0 DDR3 1GB 1.99GHz 800 Fansink

∆

♦,●

Double X, S, DX1 3

HD-485X-YNF(*) HD 4850

Standard

625 PCI-E 2.0 DDR3 512MB 1.99GHz 800 Fansink

∆

■,○

Double X, S, DX1 3

HD-485X-YDF(*) HD 4850

Standard

625 PCI-E 2.0 DDR3 512MB 1.99GHz 800 Fansink

∆

♦,●

Double X, S, DX1 3

HD-467X-ZDF(*) HD 4670

Standard

750 PCI-E 2.0 DDR2 1GB 800MHz 320 Fansink

∆

♦,●

Standard S, DX1 --

HD-467X-YAF(*) HD 4670

Standard

750 PCI-E 2.0 DDR2 512MB 800MHz 320 Fansink

∆

■,○,●

Standard S, DX1 --

HD-467X-DDF(*) HD 4670

Standard

750 PCI-E 2.0 DDR3 1GB 1.6GHz 320 Fansink

Yes

■,○,▲

Standard S, DX1 --

HD-467X-YHF(*) HD 4670

Standard

750 PCI-E 2.0 DDR3 512MB 1.8GHz 320 Fansink

Yes

■,○,▲

Standard S, DX1 --

HD-465X-ZDF(*) HD 4650

Standard

600 PCI-E 2.0 DDR2 1GB 1GHz 320 Fansink

∆

♦,●

Standard S, DX1 --

HD-465X-YAF(*) HD 4650

Standard

600 PCI-E 2.0 DDR2 512MB 800MHz 320 Fansink

∆

■,○,●

Standard S, DX1 --

HD-457X-ZAF(*) HD 4570

Standard

650 PCI-E 2.0 DDR2 1GB 1GHz 80 Fansink

∆

■,○,●

Low S, DX1 --

HD-455X-ZAF(*) HD 4650

Standard

625 PCI-E 2.0 DDR2 1GB 800MHz 80 Fansink

∆

■,○,●

Low S, DX1 --

HD-455X-YAF(*) HD 4550

Standard

625 PCI-E 2.0 DDR2 512MB 1GHz 80 Fansink

∆

■,○,●

Low S, DX1 --

HD-435X-YAH(*) HD 4350

Standard

600 PCI-E 2.0 DDR2 512MB 800MHz 80 Heatsink

∆

■,○,●

Low DX1, M --

HD-435X-ZAH(*) HD 4350

Standard

600 PCI-E 2.0 DDR2 1GB 800MHz 80 Heatsink

∆

■,○,●

Low DX1, M --

HD-435X-YNH(*) HD 4350

Standard

600 PCI-E 2.0 DDR2 512MB 800MHz 80 Heatsink

Yes

■,○,▲

Low DX1, M --

HD-435X-UAH(*) HD 4350

Standard

600 PCI-E 2.0 DDR2 256MB 1GHz 80 Heatsink

Yes

■,○,▲

Low DX1, M --

Outputs - ○ VGA, □ DVI,

◊

Dual DVI, ● S-Video and HDTV, ■ DVI w/ Dual-link, ♦ Dual DVI w/ Dual Dual-link,

♥

DMS-59 Output, ▲ HDMI, ♠ Display Port , ∆ Supports HDMI with Upgrade Kit,

Featu res - X=CrossFireX, S=Stream Technology, M=HyperMemory, DX1=DirectX10.1, D11=DirectX11, EF=Eyefinity

Model Number

Chipset

Version Clk(MHz) Bus Type Type Size Speed

••

Stream

Cooling HDMI Outputs Profile Features CrossfireX

HD-465X-ZPF(*) HD 4650

Standard

600 AGP DDR2 1GB 800MHz 320 Fansink

∆

♦,●

Standard DX1 --

HD-465X-YPF(*) HD 4650

Standard

600 AGP DDR2 512MB 800MHz 320 Fansink

∆

■,○,●

Standard DX1 --

Outputs - ○ VGA, □ DVI,

◊

Dual DVI, ● S-Video and HDTV, ■ DVI w/ Dual-link, ♦ Dual DVI w/ Dual Dual-link,

♥

DMS-59 Output, ▲ HDMI, ∆ Supports HDMI with Upgrade Kit

Featu res - X=CrossFireX, S=Stream Technology, M=HyperMemory, DX1=DirectX10.1

PCI-Express Products

XFX ATI

AGP Products

XFX ATI

Performance Main Stream

Enthusiast
