User's Manual

6
2.2 Cable Harness Description
Pin
#
Wire
Color
Pin
Name
Functional Description
Port Characteristic
1
White
IN1
Wake up pin
8V to 24V, Internally pulled low
2
Yellow
N/A
N/A
N/A
3
Black
Ground
Ground
4
Green
N/A
N/A
N/A
5
Blue
UART-Rx
3.3V Logic Interface
Com Port Settings:
Baud rate: 115200 bps; Flow control:
None; 8N1
6
Brown
UART-Tx
3.3V Logic Interface
Com Port Settings:
Baud rate: 115200 bps; Flow control:
None;8N1
7
Red
VBATT
Main battery voltage, DC
8V-24 V
8
Orange
N/A
N/A
N/A
2.3 LED Description
LED
Description
Status
Sigfox (Auburn)
Idle or Sleep Mode
OFF
Transmitting
ON
