INSTRUCTIONS Please read all instructions carefully before using
CONTENTS Panel function description Remote control function Turn the Unit On/Off Access main interface U Disc/SD Card function operation Radio Function Operation BT Function Operation External input operation (Optional) Steering wheel setting EQ setting Other Function Operations Access setup interface Audio setup Date setting General setting System setting Language setting Touch calibration Trouble shooting 01 02 03 05 05 05 06 07 08 08 08 08 09 09 09 09 09 09 10 10 Touch calibrate If touch calibration e
Access setup interface Panel function description Click [Setup] icon on main interface to access setup interface. Audio setting Click [AUDIO] icon on setup interface to access audio setting interface. You can turn on or turn off the existing functions on audio setting interface and adjust the rearview volume. Date setting Click [DATE] icon on setup interface to access time setting interface. Click [24 Hour] icon on time bar [Time Mode 24 Hour] time setting interface shall display, Can be set time mode.
Remote control function 1. (Power) button Press the button to turn power on/off. 2. MODE (mode switch) button When the power is on, each time the button is pressed, the mode switches between RADIO/USB/SD (MMC) /AUX. 3. (Mute) button Press the button to turn off volume output, repress the button to resume previous volume level. 03 4. Number button .Number button 1/2NT (track browse & playback) Under FM/AM radio status, short press the button to get into the corresponding stored radio channels.
BT Function Operation 1. Enter/exit Touch [ BT ] icon in the main interface to enter the BT interface (PIC 1). Touch icon to exit BT interface. 2. Pair/link To use BT hand-free function, make connection first, i.e. match the host with the BT mobile phone. PIC 1 Operation methods: Set the host to be matching state, and open the BT of your mobile phone and use the mobile phone to search device, the mobile phone shall prompt to match password with the BT when it has searched the BT device.
Radio Function Operation Turn on/off Host When the ignition switch is put in ACC or ON position, Press [ hold [ ] button for 3 seconds , the host will turn off. ] button on the front panel to turn on the unit. After the host starts, Access main interface Turned on, the interface to return the icon to switch to the main interface. As shown below: Touch the function icons so as to access the corresponding function operations.
