Welcome Welcome to the Xplore Technologies® iX104™, the rugged pen tablet designed, tested, and manufactured to meet the environmental and physical real-world challenges faced by today’s mobile workers. The iX104 not only works the way you do, but can also take the abuses of everyday wear and tear. The iX104 design is based on years of experience in rugged mobile applications. Advanced technology, innovative design, and a rugged case are just a few highlights of your iX104 system.
Welcome Who this handbook is for This handbook provides instructions for using the Xplore Technologies iX104 Pen Tablet (iX104) and iX104 Pen Tablet PC (iX104-TPC). This handbook assumes that you have basic experience using computers and Microsoft® Windows®.
Welcome About your computer The iX104 and the iX104-TPC are high-performance, pen-based computers that support Microsoft Windows XP® Professional Tablet PC Edition, Windows XP Professional, and Windows 2000 Professional operating systems. The iX104 has a touch screen that you control by using your finger, the pen included with the iX104, or any suitable pointing device. The iX104-TPC has an active screen that you control by using the special, enhanced pen included with the iX104-TPC.
Welcome Package contents Check to make sure your iX104 package includes the following items: ■ Battery pack ■ Power cord ■ AC adapter ■ Screen protectors (2) ■ Pen ■ Pen tether ■ iX104 pen tablet or iX104-TPC pen tablet PC ■ Warranty information kit ■ This handbook Optional accessories Your package also includes any optional accessories you ordered.
Welcome Optional accessories (continued) Storage options • External USB floppy disk drive • External USB CD-ROM drive Memory • 512 MB SODIMM, 133 MHz • 40 GB 2.5-inch rugged hard disk Power options • AC adapter with U.S.
Welcome Contacting Xplore If you purchased your iX104 from an authorized Xplore dealer, contact the dealer for service and support. If you purchased your iX104 directly from Xplore, use any of the following methods to contact Xplore for service and support: Toll free 1-866-296-8541, extension 222 Fax 1-512-336-7791 E-mail support@xploretech.com Web site http://www.xploretech.
1 Getting Started This chapter gives you an overview of your iX104 and includes a quick-start guide to iX104 keys. Getting to know your iX104 For more information about each component, see Chapter 2. This section shows the locations of some of your computer’s important components.
Chapter 1. Getting Started Getting to know your iX104 Built-in microphone – Enables you to input mono audio. Includes noise cancellation. Reset switch – Enables you to turn off the computer when using the Power On/Off key is not effective. (See page 35.) Speakers – Enable you to listen to stereo audio files. Sealed to provide protection from the environment. Ambient light sensor – Automatically controls the amount of backlight sent to the screen.
Chapter 1. Getting Started Getting to know your iX104 Antenna covers – For optional wireless LAN and WAN models, protect and secure the radio antennas (accessible by authorized service personnel only). Pen – The main device you use to enter data and control applications (instead of a mouse or a keyboard). Also called the stylus. See “Using the pen” on page 39. Pen holder – Provides a place to secure the pen when you are not using it. Battery release latch – Provides access to the battery.
Chapter 1. Getting Started Getting to know your iX104 Top view Power On/Off/ Suspend/Resume key air flow vents Kensington lock slot XPL expansion port Power On/Off/Suspend/Resume key – Press the key to turn the computer on or off, or to suspend or resume operation. Air flow vents – Helps prevent the computer from overheating by forcing heat away from the computer. (Do not block the vents.) Contact your reseller for information about the XPL expansion module and the Kensington security cable.
Chapter 1. Getting Started Getting to know your iX104 Bottom view USB port power connector headphone connector microphone connector LAN connector FireWire (IEEE 1394) connector external monitor connector The connectors on the bottom of the computer are located behind the outer doors. Power connector – For the optional AC adapter or auto adapter. (See “Optional accessories” on page 16.) The optional Office and Vehicle Docks include additional USB ports. See “Optional accessories” on page 16. USB 2.
Chapter 1. Getting Started Getting to know your iX104 Right side view XPL expansion port bumpers Bumpers – Fabricated from rugged material. Raised to help protect the computer from damage. Contact your reseller for information about the XPL expansion module and the Kensington security cable. 24 XPL expansion port – A USB port (compliant with USB Standard Revision 1.1) that enables you to connect an XPL snap-on expansion module for devices such as cameras, radios, and fingerprint scanners.
Chapter 1. Getting Started Getting to know your iX104 Left side view docking connector for the optional Xplore Tablet Dock guide pin receptacles See “Optional accessories” on page 16. Docking connector – Enables you to connect the optional Xplore Tablet Dock. Guide pin receptacles – Help assure secure connection of the optional Xplore Tablet Dock.
Chapter 1. Getting Started Getting to know your iX104 LED indicators The LED indicator lights show the status of system functions such as power and battery levels. Status LED Brightness LED The following table defines the various LED states. Table 1 Status LED indicator 26 Mode/State LED State Meaning On state green, continuous The computer is on, ready for use, and functioning normally. The battery is fully charged.
Chapter 1. Getting Started Getting to know your iX104 Table 1 Status LED indicator (continued) Mode/State LED State Meaning On state red, blinking The computer is powered on, running under battery power, and the charge level in the battery is at a minimum warning level. Plug the computer into an AC/DC power source or install a charged battery. On state red, continuous • The computer is on, running under battery power, and the charge level in the battery has reached a critical level.
Chapter 1. Getting Started Quick-start guide Quick-start guide This section is a quick guide to using the main features of your computer. (See Chapter 2 for detailed information.
Chapter 1. Getting Started Quick-start guide Table 3 Main keys Press this key... To perform this function • Log on after resuming operation from power management, powering on, or locking. • After logging on, launch Windows Task Manager. Rotate screen orientation between portrait (vertical) and landscape (horizontal). Use in combination with another key to perform various functions. (See page 30.) Toggle between programs and/or windows (the same as pressing Alt-Tab on a keyboard).
Chapter 1. Getting Started Quick-start guide Table 4 Function mode keys Press these keys... To perform this function Dim the brightness of the LCD backlight. Increase the brightness of the LCD backlight. Send video display to a monitor or projection panel connected to the computer (and back to the computer again). (This key combination is not programmable.) Default function: Select the input device. You can program this key combination to perform a different function.
Chapter 1. Getting Started Quick-start guide Navigation keys The following illustrations and tables provide a quick reference for using the navigation keys. Navigation controls with the tablet in portrait mode scroll up joystick scroll right scroll left scroll down Press the Function key... and move the joystick in this direction...
Chapter 1. Getting Started Quick-start guide Navigation controls with the tablet in landscape mode scroll up joystick scroll right scroll left scroll down Press the Function key... and move the joystick in this direction...
2 Using the iX104 This chapter contains detailed instructions for using your computer. Turning on the computer 1. Make sure the computer is off. When the computer is off, the Status LED is off. 2. Make sure the battery is charged or that the computer is plugged in to an external power source. 3. Press the Power On/Off/Suspend/Resume button.
Chapter 2. Using the iX104 Turning off the computer Turning off the computer When the computer is in Suspend mode, the Status LED is continuously yellow. 1. If the computer is in Suspend mode, press the Power On/Off/ Suspend/Resume button to resume operation. (See page 37 for information about Suspend mode.) Power On/Off/ Suspend/Resume button 2. Make sure the battery is charged or that the computer is plugged in to an external power source. 3. Save your work and close all programs. 4.
Chapter 2. Using the iX104 Turning off the computer Using the Reset switch If the computer does not seem to be accepting input and you cannot turn it off by using the method described in “Turning off the computer,” press the Reset switch. (Use a ball point pen or similar instrument to press the switch). Reset switch Note Use the Reset switch only if you cannot turn off the computer by any other means, because you may lose unsaved data.
Chapter 2. Using the iX104 Suspending and resuming operation Suspending and resuming operation To conserve battery power when you do not want to turn off the computer or when you need to install a charged battery pack, put the computer into Suspend mode. (You can suspend operation without closing any programs or Windows.) When you suspend operation: ■ Programs that are running stop (but do not close). ■ Active data is saved.
Chapter 2. Using the iX104 Suspending and resuming operation Notes If you have set your computer to turn power off (in the Power Options utility in Windows Control Panel), you cannot suspend operation. To change power settings, see “Using power options” on page 58. If the Suspend action of the Power On/Off/Suspend/Resume button has been disabled to prevent accidental interruption, pressing the button does not suspend the computer. You must use a software application to suspend the computer.
Chapter 2. Using the iX104 Suspending and resuming operation 3. Press Stand By. When operation is suspended, the Status LED displays a continuous yellow light. Status LED Resuming operation To resume operation when the computer is in Suspend mode, press the Power On/Off/Suspend/Resume button. Note Press the button only once.
Chapter 2. Using the iX104 Using the pen After a minute or two, the computer resumes normal operation. When the Status LED displays a continuous green light, you can begin using the computer. Note Resuming operation from Hibernation mode takes a little longer than from Suspend-to-RAM mode. Using the pen You can use the pen to select items and to navigate through programs. If your computer is an iX104-TPC (active screen): Use the special multi-function pen provided with the computer.
Chapter 2. Using the iX104 Using the pen Using the pen to perform mouse functions To perform this function... Do this right-click icon right-click button 40 Select an object (left button click). Tap the pen tip once on the object. Perform a double-click. Quickly tap the pen tip twice on the object. Perform a right-click. If your computer is an iX104 (touch screen): In the Windows taskbar, press the right-click icon; then click the object.
Chapter 2. Using the iX104 Using the pen Changing the pen double-click speed The pen double-click speed is in sync with the mouse double-click speed. To change the speed: 1. Click the Windows Start button. 2. Click the Settings option. 3. Click the Control Panel option. 4. In the Control Panel window: If your computer is an iX104 (touch screen): Click the Pointer Devices icon. If your computer is an iX104-TPC (active screen): Click the Tablet and Pen Settings icon. 5. Click the Windows tab. 6.
Chapter 2. Using the iX104 Using the pen Positioning the pen and pen tether The pen tether helps prevent the loss of your pen. The following illustration shows how to position the pen and pen tether.
Chapter 2. Using the iX104 Using the joystick (the navigation control key) Using the joystick (the navigation control key) joystick (navigation control key) Press the joystick to perform the same functions as pressing Enter on a keyboard. Push the joystick up, down, left or right to move a highlighted item accordingly (the same as pressing the arrow keys on a keyboard). Use the Fn key in combination with the joystick to perform other functions, such as Page Up and Tab.
Chapter 2. Using the iX104 Changing the screen orientation Changing the screen orientation To rotate the screen orientation from portrait (vertical) to landscape (horizontal) mode or from landscape to portrait mode, press the screen rotation key.
Chapter 2. Using the iX104 Adjusting the screen brightness Adjusting the screen brightness To dim the brightness of the LCD backlight: Press the Function key and the Windows toggle key. To increase the brightness of the LCD backlight: Press the Function key and the Windows Start key.
Chapter 2. Using the iX104 Docking the iX104 Docking the iX104 If you have the optional Xplore Tablet Dock (see “Optional accessories” on page 16), connect it to the iX104 at the docking port.
Chapter 2. Using the iX104 Connecting devices Connecting devices Refer to the following subsections for information about connecting external devices to your computer. Note If the device you want to use does not appear to be working with your computer, the device may need to be enabled in the computer’s configuration program. Contact your local help desk or Xplore reseller.
Chapter 2. Using the iX104 Connecting devices Connecting to a local area network Connect a local area network (LAN) cable’s RJ-45 connector to the internal LAN interface card. (See your network system administrator for more information.) LAN connector Connecting USB-compatible devices Devices must be in compliance with USB Standard Revision 2.0. Connect any USB-compatible device to the computer’s USB port.
Chapter 2. Using the iX104 Connecting devices Connecting an external microphone microphone connector Adjusting microphone volume If necessary, adjust the volume of the microphone as follows: 1. Press the Windows Start key. 2. Click the Control Panel option. 3. In the Control Panel window, double-click the Sounds and Audio Properties icon. 4. In the Sounds and Audio Properties window, click the Audio tab. 5. In the Sound recording area, click the Volume button. 6. Adjust the volume. 7. Click OK.
Chapter 2. Using the iX104 Connecting devices Connecting a headphone or speakers headphone/speakers connector Adjusting headphone or speaker volume 1. Click the audio icon in the Status area of the Windows taskbar. The volume control area opens. 2. If the Mute check box is checked, uncheck it. 3. Move the slider bar up or down to increase or decrease the volume.
Chapter 2. Using the iX104 Connecting devices Connecting a monitor or projection panel Monitor/projection panel connector Activating the monitor or projection panel To change the video output to the monitor or projection panel: Press the Fn-P1 key combination. To change the video output back to the computer screen: Press the Fn-P1 key combination again.
Chapter 2.
Chapter 2. Using the iX104 Using the battery Using the battery You can recharge, remove, and replace the battery pack. Charging the battery pack If you do not have an external battery charger Follow these steps to charge the battery while it is installed in the computer: 1. Connect a power source, such as an AC adapter or cigarette lighter adapter, to the power connector on the computer. power connector If the battery charge is below 90%, the battery begins charging and the Status LED flashes green.
Chapter 2. Using the iX104 Using the battery 2. Check the level of charge. (See “Checking battery power status” on page 59.) The charging process continues until the battery charge reaches 100%. Table 5 shows the approximate time required to charge the battery level to 100%. Table 5 Approximate battery charge time Battery pack capacity Charge time when the computer is not in use Charge time when the computer is in use* 4500 mAh 2.5 hours 3.5 hours 9000 mAh 3.5 hours 5.
Chapter 2. Using the iX104 Using the battery Removing and installing the battery You can remove the battery and use an (optional) external charger to charge it. Removing the battery 1. To swap with a charged battery: Use one of the methods described in “Suspending operation” on page 37 to suspend operation. If a charged battery is not available: Save your work and close all running programs; then shut down the computer or put the computer in Hibernation mode (see “Suspending operation” on page 37).
Chapter 2. Using the iX104 Using the battery 2. On the computer, slide the battery release latch in the direction indicated. removable battery battery release latch 3. Pull the battery away from the computer and remove it. Note After removing the battery, you must replace the battery or connect the computer to an external power supply within 3 to 5 minutes or the computer completely loses power.
Chapter 2. Using the iX104 Using the battery Installing the battery 1. Orient the battery with the slides in the empty battery tray. 2. Slide the battery into the tray and press it firmly until it is seated. The battery release latch returns to its original position and locks the battery in place. Discarding a battery Dispose of a spent battery in accordance with your local government regulations. Under Federal, state, or local law, it may be illegal to put batteries in the trash.
Chapter 2. Using the iX104 Using the battery Using power options This section explains how to use the Power Options Properties window to manage the computer’s power use. On the Windows taskbar, click the battery icon. The Power Options Properties window opens. Changing the computer’s power schemes In the Power Options Properties window, select the Power Schemes tab; then select options from the drop-down lists.
Chapter 2. Using the iX104 Using the battery Changing battery alarm settings In the Power Options Properties window (page 58), select the Alarms tab; then use the slider bars to change the alarm settings. Checking battery power status In the Power Options Properties window (page 58), select the Power Meter tab. The window shows the amount of power left in the battery.
Chapter 2. Using the iX104 Using the battery Selecting power settings In the Power Options Properties window (page 58), select the Advanced tab; then select the power settings options you want to use. Enabling Hibernation mode In the Power Options Properties window (page 58), select the Hibernate tab; then check the Enable Hibernation check box.
Chapter 2. Using the iX104 Using the battery Tips for conserving battery power The following tips help you extend the life of your battery by conserving battery power: iX104 User’s Handbook ■ Use an external power source such as the AC or auto adapter whenever available. ■ Suspend operation if you know that you will not be using the system for a while. (See “Suspending operation” on page 37.) ■ Turn off the computer if you will not be using it for an extended period of time.
Chapter 2. Using the iX104 Programming hot keys Programming hot keys Xplore pre-programs the P1, P2, and P3 hot keys and Function mode hot key combinations to perform certain functions by default. However, you can program them to perform different functions, as described in this section. Table 6 Key Programmable hot keys Default function Starts Help. Starts Internet Explorer. Starts your email application.
Chapter 2. Using the iX104 Programming hot keys Programming hot keys to start applications, open documents, or go to a Web site 1. In the Status area of the Windows taskbar, click the iX104 Configuration icon. The Launch Button QuickShow dialog box opens. 2. Click the Configure button. The Panel Control Center window opens.
Chapter 2. Using the iX104 Programming hot keys 3. Click the Change button next to the key or key combination you want to program. The following options appear: 4. Click Launch an Application, Document or Web site.
Chapter 2. Using the iX104 Programming hot keys 5. To start an application: a Click Launch an Application. b In the File text box, type the name of the application you want the hot key or Function mode hot key combination to start. Note: Type the name of executable file that starts the application. For example: word.exe, notepad.exe, excel.exe. c Click Change. To open a document: a Click Open a Document.
Chapter 2. Using the iX104 Programming hot keys To open a multimedia file: a Click Open a Multimedia file. b In the File text box, type the name of the multimedia file you want the hot key or Function mode hot key combination to open. (For example: 911training.dir, demo.ppt) c Click Change. To open a Web page: a Click Open a Web page. b In the File text box, type the URL of the Web page you want the hot key or Function mode hot key combination to open. (For example: http://www.xploretech.
Chapter 2. Using the iX104 Programming hot keys Programming hot keys to perform pre-defined functions 1. In the Status area of the Windows taskbar, click the iX104 Configuration icon. The Launch Button QuickShow dialog box opens. 2. Click the Configure button. The Panel Control Center window opens. 3. Next to the key or key combination you want to program, click the Change button.
Chapter 2. Using the iX104 Programming hot keys The following options appear: 4. Click Start a pre-defined function. 5. In the Function selection drop-down list, select an option. 6. Program more hot keys, or click Finish to close the Panel Control Center window.
Chapter 2. Using the iX104 Programming hot keys Programming hot keys to perform other key functions 1. In the Status area of the Windows taskbar, click the iX104 Configuration icon. The Launch Button QuickShow dialog box opens. 2. Click the Configure button. The Panel Control Center window opens. 3. Next to the key or key combination you want to program, click the Change button.
Chapter 2. Using the iX104 Programming hot keys The following options appear: 4. Click Press a key or key combination.
Chapter 2. Using the iX104 Programming hot keys 5. If you want the hot key or hot key combination to perform the function of a single key: a If the Ctrl, Alt, or Shift boxes are checked, uncheck them. b Click the key you want the hot key or hot key combination to perform. (For example: F6, G, or Caps Lock) If you want the hot key or hot key combination to perform the function of a key combination: a Check the Ctrl, Alt, or Shift box.
iX104 User’s Handbook
3 Maintaining the iX104 This chapter provides instructions for maintaining your computer. Caring for the computer This section provides information about how to keep your computer in top working condition. Checking power cords and connectors Check AC and DC power cords and power connectors periodically for damage. Replace the power cord immediately if you find any damage.
Chapter 3. Maintaining the iX104 Caring for the computer Preventing the computer from overheating The computer monitors its internal temperature. As the internal temperature approaches the tolerable limits of heat-sensitive components, system functions are automatically limited or turned off to prevent damage. To prevent the computer from overheating, do not obstruct the computer’s air vents.
Chapter 3. Maintaining the iX104 Caring for the computer Storing the computer You can store the computer in the Off state for about 30 days with a fully charged battery installed. After this period, recharge the battery or replace it with a charged battery. If you intend to store the computer for more than 30 days, remove the battery pack and keep it in a cool place.
Chapter 3. Maintaining the iX104 Caring for the computer Caring for the display screen To clean the display screen, dampen a soft cotton cloth with water or isopropyl alcohol and gently wipe the screen surface. Protecting the display screen The screen protector is a durable, replaceable writing surface that protects the display screen from abrasion. To obtain additional screen protectors, check with your reseller, or go to the Xplore Web site at www.xploretech.com for ordering information.
Chapter 3. Maintaining the iX104 Caring for the computer Installing a new screen protector 1. If a screen protector is already installed on the display screen, remove it before installing the new screen protector. 2. Using a soft cotton cloth dampened with isopropyl alcohol, gently clean the screen. Make sure that you have removed all residue from the screen before you apply the new screen protector. 3. Remove the protective coating from the back (the shiny side) of the screen protector. 4.
Chapter 3. Maintaining the iX104 Caring for the computer 5. Place the screen protector on the screen surface. Use your fingers to apply pressure to the protector, using a continuous wiping motion along the edges. To ensure a good seal between the screen protector and the display, do not lift the screen protector from the display after you have applied it. 6. Remove the protective plastic cover from the face of the screen protector. 7.
Chapter 3. Maintaining the iX104 Calibrating the pen Calibrating the pen Calibrating the pen adjusts the cursor position on the screen relative to the position of the pen tip. Calibrate the pen to adjust the distance error between where the pen is actually touching the screen and where the computer is registering the pen touch. You may need to calibrate the pen in the following situations: ■ You are using the pen for the first time.
Chapter 3. Maintaining the iX104 Calibrating the pen 2. Click the Pointer Devices icon. The Pointer Device Properties window opens. 3. Click Calibrate. The Calibration program starts. 4. Follow the instructions that appear on the screen. 5. When you finish, click OK.
Chapter 3. Maintaining the iX104 Calibrating the pen Calibrating the pen for an iX104-TPC active screen 1. From the Start menu, select Control Panel. The Control Panel opens. Tablet and Pen Settings icon 2. Click the Tablet and Pen Settings icon.
Chapter 3. Maintaining the iX104 When to replace the pen The Tablet and Pen Settings window opens. 3. In the Calibration area drop-down list, select the mode for which you want to calibrate the pen: Landscape or Portrait; then click Calibrate. The Calibration program starts. 4. Follow the instructions that appear on the screen. 5. When you finish, click OK. When to replace the pen With use, the pen tip may become worn and can scratch the screen.
A Troubleshooting Table 8 contains solutions to some problems. If you cannot solve the problem by taking the actions described, contact your local help desk or your reseller for further assistance. Table 8 Troubleshooting Problem Possible cause and solution Computer will not start. • The battery may be defective or discharged to a critically low level. Connect an external power supply (such as the AC adapter) or install a charged battery. See “Using the battery” on page 53.
Appendix A. Troubleshooting Table 8 Troubleshooting (continued) Problem Possible cause and solution Display screen is blank or difficult to read. • Confirm that the computer is on (the Power icon is displayed continuously in the Status area). • The brightness may be set too low, causing the screen to appear too dark. To change system brightness, press the Fn and Start keys to open the Xplore menu and adjust the brightness. (See page 30.) • An external monitor may be selected.
Appendix A. Troubleshooting Table 8 Troubleshooting (continued) Problem Possible cause and solution Headphone or speaker volume is too low. • The volume may be in Mute mode or set too low. Follow the instructions in “Adjusting headphone or speaker volume” on page 50. • Make sure the volume control in your audio software is set to an audible level. An external device is not working with the computer. The device may need to be enabled in the computer’s configuration program (BIOS Setup).
iX104 User’s Handbook
B Using BIOS and AOS Functions This appendix explains how to use the application and navigation buttons with the Basic Input-Output System (BIOS) program and the Advanced Operating System (AOS) Options menu. Note These functions are typically for use only by your system administrator or by authorized service technicians. Table 9 Using BIOS and AOS functions Use this button...
Appendix B. Using BIOS and AOS Functions Table 9 Using BIOS and AOS functions (continued) Use this button... To perform this function When the system is displaying a BIOS error (such as an invalid checksum), press the P1 button to bypass the error message and attempt a normal boot sequence (the same as the F1 key on a keyboard). When the system is displaying the iX104 logo, press the P2 button to run the BIOS setup utility (the same as the F2 key on a keyboard).
Appendix B. Using BIOS and AOS Functions Enabling manual LCD backlight control Enabling manual LCD backlight control When the LCD backlight control is in manual mode, the ambient light sensor is disabled and the computer no longer automatically controls the screen brightness. Follow these steps to disable the sensor and enable manual LCD backlight control: 1. When the computer is booting, press the Function and P2 buttons to start the BIOS Setup Utility.
Appendix B. Using BIOS and AOS Functions Enabling manual LCD backlight control 2. Select the LCD tab. 3. In the LCD Backlight Control drop-down list, select Manual. 4. Click OK.
C Glossary Adapter. A device that provides an interface between two dissimilar electronic devices. For example, the AC adapter modifies the power from a wall outlet for use by the computer. Advanced Power Management (APM). A facility consisting of one or more layers of software that support power management. The APM software interface enables applications, operating systems, device drivers, and the APM BIOS to work together to reduce power consumption. Alternating Current (AC).
Appendix C. Glossary Compact Disk-Read Only Memory (CD-ROM). Stores data on metal-plated plastic discs. Compatibility. 1.The ability of one computer to accept and process data in the same method as another computer without modifying the data or the media upon which it is being transferred. 2.The ability of one device to connect or communicate with another system or component. Configuration. The specific combination of hardware components of the computer, and their operating status.
Appendix C. Glossary Interface. 1. Hardware and/or software components used specifically to connect one computer or device to another. 2. To physically connect one system or device to another to exchange information. 3. The point of contact between user, the computer, and the program (for example, the pen/stylus or a menu). Kilobyte (KB). A unit of 1024 bytes measuring storage space, typically in memory or on storage media such as a diskette or hard disk drive. Local area network (LAN).
Appendix C. Glossary Port. The electrical connection through which the computer sends and receives data to and from devices or other computers. Program. A set of instructions a computer can execute to tell the system what to do and how to do it. Random Access Memory (RAM). A hardware component of your computer that temporarily stores active program code and data. Reset. The act of reloading the operating system. Resolution. The number of pixels displayed on the screen.
D Hardware Specifications This appendix provides specifications for the iX104. Physical specifications Dimensions 11.20” x 8.25” x 1.6” (WxHxD) 283.9mm x 209.3mm x 40.8mm Weight 4.45 lbs. (2.02kg)* Processing specifications CPU Pentium III with SpeedStep technology* Chip set 133MHz Processor speed 866 MHz* * Varies according to your computer’s configuration.
Appendix D. Hardware Specifications Memory/storage specifications Main RAM • 256MB SDRAM (on-board/PC133) • 144-pin SODIMM modules 512MB module available. Special rugged memory modules: conformal coated and custom locking tabs to protect against moisture and vibration L1 Cache (CPU) 32KB on-die L2 Cache 512KB on-die BIOS ROM 8Mbit (FWH) Hard Disk Drive 2.5” HDD shock mounted Minimum 20GB IDE HDD* Ultra DMA 100 BIOS ROM 8Mbit (FWH) * Varies according to your computer’s configuration.
Appendix D. Hardware Specifications Display specifications Display • Color LCD • Active Digital Sensor and Pen • or Passive Palm Rejection Touch Panel • 32-bit True color • 10.4” TFT XGA (1024x768), 16M colors • Brightness: 16 levels • Viewing Angle: • Horizontal: 30 degrees (min.) • Vertical: 10 degrees (min.) • Contrast Ratio: Typ.
Appendix D. Hardware Specifications Interface specifications Wireless Radio Bays • One internal Type 1 or Type II PC Card slot (PCMCIA Cardbus version 3.0) • One Internal mini-PCI slot • One internal OEM radio bay for RIM 1902G and 1802G GSM/GPRS radios Integrated Interfaces • DC-in • USB (1) 2.
Appendix D. Hardware Specifications Power specifications Main Battery • 2 cell • Removable Lithium Ion Polymer • 10.8V @ 4500mAh • Warm-swappable • Recharge Time: • Suspend Life: Min. 5 days • Off State: Approximately 30 days Optional Spare Battery • 4 cell • Removable Lithium Ion Polymer • 10.8V @ 9000mAh • Warm-swappable • Recharge Time: • Suspend Life: Min.
Appendix D. Hardware Specifications Environmental specifications Temperature • Operating: -4o to 140o F (-20o to 60o C) • Storage: -40o to 167o F (-40o to 75o C) Humidity 0% to 95% non-condensing Shock/Drop Three-foot drop to concrete, all surfaces, edges and corners Vibration 0.04g^2/Hz, 20 Hz - 1000 Hz -6dB/octive 1000 Hz - 2000 Hz Enclosure Class Blowing rain: 4”/hr, 40 mph wind and MIL-STD-810F Method 506.4 Procedure 1 Drip: 7 gal/ft2/hr MIL-STD-810F Method 506.
Appendix D.
iX104 User’s Handbook
E Agency Notices FCC notices This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Modifications not expressly approved by Xplore Technologies could void this user’s authority to operate the equipment.
Appendix E. Agency Notices RF eposure Tests for SAR are conducted using standard operating positions specified by the FCC with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operation can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network.
Appendix E. Agency Notices Health and Safety Information Exposure to Radio Frequency (RF) Signals Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population.
Appendix E. Agency Notices DOC (Industry Canada Notices) Notice to Users of Radio and Television This Class B digital apparatus meets all requirements of Canadian Interference-Causing Equipment Regulations CET appareil numérique de la class B respecte toutes les exigence du Réglement sur le matérial brouilleur du Canada. Notice to Users of the Canadian Telephone Network Notice This equipment meets the applicable Industry Canada Terminal Equipment Technical Specifications.
Appendix E. Agency Notices Notice The Ringer Equivalence Number (REN) for this terminal equipment is 0.0. The REN assigned to each terminal equipment provides an indication of the maximum number of terminals allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the Ringer Equivalence Numbers of all the devices does not exceed five.
Appendix E. Agency Notices For authorized repair technicians only a WARNING For continued protection against risk of fire, replace only with the same type and rating fuse. a WARNING Danger of explosion if Lithium (clock) battery is incorrectly replaced. Replace only with the same equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instruction.
