Operation Multi 3420
24
ba75864e11 02/2011
Note
The login is done immediately if no password is required.
If a sensor is connected the measured value display appears.
Note
The user specifies the password when he or she first logs in with a user
name.
A valid password consists of 4 digits.
The user can change the password with the next login.
2 Using <S><T>, enter the Benutzername menu item and con-
firm with <MENU/ENTER>.
The user name is highlighted.
3Using <S><T>, select a user name and confirm with <MENU/
ENTER>.
4 If a password is required:
Using <S><T>, enter the Password menu item and confirm
with <MENU/ENTER>.
5 Change the digit of the highlighted position with <S><T>.
Go to the next digit of the password with <W><X>.
When the password was completely entered, confirm with
<MENU/ENTER>.
The login takes place. If a sensor is connected the measured
value display appears.
User name Admin
Password ####
Change password
Login
22.09.2009 08:00
