Multi 3420 Operation
25
ba75864e11 02/2011
Changing the password If the administrator has set up the access with password protection:
Forgotten the
password?
Contact the administrator.
1 Switch on the meter with <On/Off>.
The Login dialog box appears.
2 Using <S><T>, enter the Benutzername menu item and con-
firm with <MENU/ENTER>.
The user name is highlighted.
3 Using <S><T>, select a user name and confirm with <MENU/
ENTER>.
4 Using <S><T>, enter the Change password menu item and
confirm with <MENU/ENTER>.
5 Enter the old password in the Password box with <S><T>
and <W><X> and confirm with <MENU/ENTER>.
6 Enter the new password in the New password box with
<S><T> and <W><X> and confirm with <MENU/ENTER>.
The password is changed.
The login takes place. If a sensor is connected the measured
value display appears.
