Multi 3430 Technical data
109
ba75865e11 02/2011
7 Technical data
7.1 General data
Dimensions Approx. 180 x 80 x 55 mm
Weight Approx. 0.4 kg
Mechanical structure Type of protection IP 67
Electrical safety Protective class III
Test certificates CE
Ambient
conditions
Storage - 25 °C ... + 65 °C
Operation -10 °C ... + 55 °C
Allowable relative
humidity
Annual mean: < 75 %
30 days/year: 95 %
Other days: 85 %
Power
supply
Rechargeable
batteries
4 x 1.2 V NiMH rechargeable batteries,
type AA
Operational life Approx. 150 h
#
Power pack
(charging device)
FRIWO FW7555M/09, 15.1432.500-00
Friwo Part. No. 1883259
Input: 100 ... 240 V ~ / 50 ... 60 Hz / 400 mA
Output: 9 V = / 1.5 A
Connection max. overvoltage category II
Primary plugs contained in the scope of de-
livery: Euro, US, UK and Australian.
USB interface (device) Type USB 1.1
USB-B (Device), PC
Baud rate adjustable:
1200, 2400, 4800, 9600, 19200 Baud
Data bits 8
Stop bits 2
Parity None
Handshake RTS/CTS
Cable length max. 3 m
USB interface (host) Type USB 2.0
USB-A (host), USB device
#
The operational life is shorter if, e.g.
- several sensors are operated
- the maximum display illumination is set
