Multi 3430 Commissioning
19
ba75865e11 02/2011
3 Commissioning
3.1 Scope of delivery
z Meter Multi 3430
z 4 NiMH rechargeable batteries 1.2 V Mignon type AA
z USB cable (A plug on mini B plug)
z Power pack
z Short instructions
z Detailed operating manual (4 languages)
z CD-ROM
3.2 Power supply
The Multi 3430 is supplied with power in the following ways:
z Battery operation with NiMh rechargeable batteries
z Mains operation with the supplied power pack.
The NiMh rechargeable batteries are automatically charged while
the power pack is connected.
z USB operation via a connected USB-B cable.
The inserted NiMh rechargeable batteries are not charged
3.3 Initial commissioning
Perform the following activities:
z Insert the rechargeable batteries and charge them
z Connect the power pack (mains operation / battery charging)
z Switch on the meter
z Set the date and time
3.3.1 Inserting the rechargeable batteries
1 Unscrew the two screws (1) on the underside of the meter.
2 Open the battery compartment (2) on the underside of the
meter.
