4.3 General operating principles
This section contains basic information on the operation of the
Multi 3430.
Operating elements,
display
An overview of the operating elements and the display is given in sec-
tion 1.1 and section 1.2.
Operating modes,
navigation
An overview of the operating modes and navigation of the Multi 3430 is
given in section 4.3.1 and section 4.3.3.
4.3.1 Operating modes
The meter has the following operating modes:
z Measuring
The measurement data of the connected sensors is shown in the
measured value display
z Calibration
The course of a calibration with calibration information, functions
and settings is displayed
z Storage in memory
The meter stores measuring data automatically or manually
z Data transmission
The meter transmits measuring data and calibration records to a
USB-B interface automatically or manually.
z Setting
The system menu or a sensor menu with submenus, settings and
functions is displayed
