Multi 3430 Operation
35
ba75865e11 02/2011
System / General / Temperature
unit
°C
°F
Temperature unit,
degrees Celsius or degrees
Fahrenheit.
All temperatures are displayed
with the selected unit.
System / General / Stability control on
off
Switches on or off the auto-
matic stability control during
measurement (see section
4.4.3)
System / Interface / USB Host on
off
Switches on or off the USB
Host interface.
You can switch off the power
supply of the USB Host inter-
face to extend the operating
time of the batteries.
The USB Host interface has to
be switched on in order to
transfer data to a USB memory
device.
System / Interface / Baud rate 1200, 2400, 4800,
9600, 19200
Baud rate of the USB Device
interface
System / Interface / Output format ASCII
CSV
Output format for data trans-
mission
For details, see section 4.12
System / Interface / Decimal sepa-
rator
Dot (xx.x)
Comma (xx,x)
Decimal separator
System / Interface / Output header Output of a header for Output
format: CSV
System /Clock function Date format
Date
Time
Settings of time and date.
For details, see section 4.3.5
System /Service information Hardware version and software
version of the meter are dis-
played.
System /Reset - Resets the system settings to
the default values.
For details, see section 4.13.2
Menu item Setting Description
