Multi 3430 Operation
37
ba75865e11 02/2011
4.5 Sensor info
You can display the current sensor data and sensor settings of a con-
nected sensor at any time. The sensor data are available in the mea-
sured value display with the [Info] softkey.
1 In the measured value display:
Display the sensor data (sensor name, series number) with
[Info].
2 Display further sensor data (settings) with [More].
30.09.2009 08:00
Info
30.09.2009 08:00More
SenTix 940
B092500013
