Operation Multi 3430
42
ba75865e11 02/2011
4.7.3 Settings for pH measurements
Overview The following settings are possible for pH measurements:
z Calibration record (display)
z Calibration data storage (display)
z Calibration interval
z Buffers for calibration
z Single-point calibration
z Unit for slope
z Resolution
Settings The settings are made in the menu for calibration and measurement
settings of the pH/ORP measurement. To open the settings, display the
required parameter in the measured value display and press the
<MENU/ENTER> key. After completing the settings, switch to the mea-
sured value display with <M>.
Default settings are printed in bold.
Menu item Possible setting Description
Calibration /Calibration record - Displays the calibration record of the last cal-
ibration
Calibration /Calibration data
storage
- Displays the last calibration records (max.
10)
Calibration / Calibration data
storage / Copy to USB flash
drive
- Outputs the calibration data storage to a con-
nected USB flash drive
Calibration / Calibration data
storage / Output to RS232/USB
- Outputs the calibration data storage to the
interface
Calibration /Buffer TEC
NIST/DIN
ConCal
...
Buffer sets to be used for pH calibration.
For further buffers and details, see section
4.7.4.
Calibration /Single-point cali-
bration
yes
no
Quick calibration with 1 buffer
Calibration /Calibration interval 1 ... 7 ... 999 d Calibration interval for the IDS pH sensor (in
days).
The meter reminds you to calibrate regularly
by the flashing sensor symbol in the measur-
ing window.
