Multi 3430 Operation
65
ba75865e11 02/2011
4.8.3 Settings for ORP measurements
Overview The following settings are possible for ORP measurements:
z Resolution
z Automatic stability control
Settings The settings are made in the menu for measuring settings of the ORP
measurement. To open the settings, display the required parameter in
the measured value display and press the <MENU/ENTER> key. After
completing the settings, switch to the measured value display with
<M>.
Default settings are printed in bold.
Menu item Possible set-
ting
Description
mV resolution 0.1
1
Resolution of the mV dis-
play
Reset - Resets all sensor settings to
the delivery condition (see
section 4.13.1)
