Operation Multi 3430
88
ba75865e11 02/2011
4.11 Data storage
You can transmit measured values (datasets) to the data storage:
z Manual storage (see section 4.11.1)
z Automatic storage at intervals (see section 4.11.2)
Each storage process transmits the current dataset to the interface at
the same time.
Measurement dataset A complete dataset consists of:
z Date/time
z Meter name, series number
z Sensor name, series number
z ID number
z Measured value of the connected sensor
z Measured temperature value of the connected sensor
z AutoRead info: AR appears with the measured value if the Auto-
Read criterion was met while storing (stable measured value). Oth-
erwise, the AR display is missing.
z Calibration evaluation:
- 4 levels (+++, ++, +, -, or no evaluation) or
- QSC (percentage)
Storage locations The Multi 3430 meter has two measurement data memories. The mea-
sured values recorded either manually or automatic are stored sepa-
rately in individual measurement data memories.
Storage Maximum number of datasets
Manual data storage 500
Automatic data storage 10000
