Operation photoLab
®
6100 VIS
114
ba75847e01 08/2009
4.12.2 Copying all measurement data files to a USB memory device
Even if no PC is directly connected to the photometer, you can very simply
transfer all measurement data files from the photometer (Internal DataB
folder) to a connected USB memory device.
A message appears while the data
are being saved.
When the data saving procedure
is finished, a message appears.
1 Confirm the message with
<STORE>.
All measurement data files from
the photometer (Internal DataB
folder)
have been transferred to
the USB memory device.
The complete folder structure from
the photometer is created on the
USB memory device. The
individual measurement data files
are stored in subfolders sorted by
measurement data types.
<HOME>
[Setup]
– Save all data on USB
memory
